Abstract:

Concerning the current lack of effective development and deployment tools for deep learning applications， a component-based development framework for deep learning applications was proposed. The framework splits functions according to the type of resource consumption， uses a review-guided resource allocation scheme for bottleneck elimination， and uses a step-by-step boxing scheme for function placement that takes into account high CPU utilization and low memory overhead. The real-time license plate number detection application developed based on this framework achieved 82% GPU utilization in throughput-first mode， 0.73 s average application latency in latency-first mode， and 68.8% average CPU utilization in three modes （throughput-first mode， latency-first mode， and balanced throughput/latency mode）. The experimental results show that based on this framework， a balanced configuration of hardware throughput and application latency can be performed to efficiently utilize the computing resources of the platform in the throughput-first mode and meet the low latency requirements of the applications in the latency-first mode. Compared with MediaPipe， the use of this framework enabled ultra-real-time multi-person pose estimation application development， and the detection frame rate of the application was improved by up to 1 077%. The experimental results show that the framework is an effective solution for deep learning application development and deployment on CPU-GPU heterogeneous servers.

Key words: deep learning application, development framework, Component-Based Development (CBD), pipeline deployment, CPU-GPU heterogeneity

摘要：

针对目前深度学习应用缺少有效的开发与部署工具的问题，提出一个面向深度学习应用的组件式开发框架。所提框架根据应用的资源消耗类型进行功能拆分，使用评测引导的资源分配方案进行瓶颈消除，使用分步装箱方案兼顾高CPU利用率和低显存开销的功能放置。基于此框架开发的实时车牌号检测应用，在吞吐优先模式下GPU利用率达到82%，在延迟优先模式下平均应用延迟达到0.73 s，在三种模式下（吞吐优先模式、延迟优先模式以及吞吐/延迟的均衡模式）下，CPU平均利用率达到68.8%。实验结果表明，基于此框架能够进行硬件吞吐与应用延迟的平衡型配置，在吞吐优先模式下高效利用平台的计算资源，在延迟优先模式下满足应用的低延迟需求。相较于MediaPipe，使用本框架能够进行超实时的多人姿态估计应用开发，应用的检测帧率最高提升了1 077%。实验结果表明，所提框架能够作为CPU-GPU异构服务器上面向深度学习应用开发部署的有效解决方案。

关键词: 深度学习应用, 开发框架, 基于组件的开发, 流水线部署, CPU-GPU异构
