Journal of Computer Applications ›› 2023, Vol. 43 ›› Issue (5): 1578-1583.DOI: 10.11772/j.issn.1001-9081.2022040606
Special Issue: 多媒体计算与计算机仿真
• Multimedia computing and computer simulation • Previous Articles Next Articles
Jianhui HE, Chunlong HU(), Xin SHU
Received:
2022-04-29
Revised:
2022-07-06
Accepted:
2022-07-07
Online:
2023-05-08
Published:
2023-05-10
Contact:
Chunlong HU
About author:
HE Jianhui, born in 1998, M. S. candidate. His research interests include computer vision, age estimation.Supported by:
通讯作者:
胡春龙
作者简介:
何建辉(1998—),男,湖南永州人,硕士研究生,主要研究方向:计算机视觉、年龄估计基金资助:
CLC Number:
Jianhui HE, Chunlong HU, Xin SHU. Multi-task age estimation method based on multi-peak label distribution learning[J]. Journal of Computer Applications, 2023, 43(5): 1578-1583.
何建辉, 胡春龙, 束鑫. 基于多峰标签分布学习的多任务年龄估计方法[J]. 《计算机应用》唯一官方网站, 2023, 43(5): 1578-1583.
Add to citation manager EndNote|Ris|BibTeX
URL: https://www.joca.cn/EN/10.11772/j.issn.1001-9081.2022040606
阶段 | 层 | 卷积核 | 输出尺寸 | 参数量 |
---|---|---|---|---|
一 | Image | — | 112×112×3 | — |
Conv1 | 3×3 | 110×110×32 | 960 | |
AvgP | 2×2 | 55×55×32 | — | |
Conv2 | 3×3 | 53×53×32 | 9 312 | |
Conv3 | 3×3 | 51×51×32 | 9 312 | |
AvgP | 2×2 | 25×25×32 | — | |
二 | Conv4 | 3×3 | 23×23×64 | 18 624 |
Conv5 | 3×3 | 21×21×64 | 37 056 | |
AvgP | 2×2 | 10×10×64 | — | |
三 | Conv6 | 3×3 | 8×8×64 | 37 056 |
Conv7 | 3×3 | 6×6×64 | 37 056 | |
总计 | — | — | — | 149 376 |
Tab. 1 Lightweight feature extraction network structure
阶段 | 层 | 卷积核 | 输出尺寸 | 参数量 |
---|---|---|---|---|
一 | Image | — | 112×112×3 | — |
Conv1 | 3×3 | 110×110×32 | 960 | |
AvgP | 2×2 | 55×55×32 | — | |
Conv2 | 3×3 | 53×53×32 | 9 312 | |
Conv3 | 3×3 | 51×51×32 | 9 312 | |
AvgP | 2×2 | 25×25×32 | — | |
二 | Conv4 | 3×3 | 23×23×64 | 18 624 |
Conv5 | 3×3 | 21×21×64 | 37 056 | |
AvgP | 2×2 | 10×10×64 | — | |
三 | Conv6 | 3×3 | 8×8×64 | 37 056 |
Conv7 | 3×3 | 6×6×64 | 37 056 | |
总计 | — | — | — | 149 376 |
类型 | 方法 | 预训练集 | 参数量/103 | MAE |
---|---|---|---|---|
重量级 | DEX[ | ImageNet | 138 000 | 3.25 |
DEX[ | IMDB-WIKI | 138 000 | 2.68 | |
Posterior[ | — | 138 000 | 2.52 | |
MV[ | IMDB-WIKI | 138 000 | 2.16 | |
DLDL[ | IMDB-WIKI | 138 000 | 2.42 | |
RankingCNN[ | Audience | 500 000 | 2.96 | |
BridgeNet[ | IMDB-WIKI | 138 000 | 2.38 | |
DORFs[ | ImageNet | 138 000 | 2.19 | |
轻量级 | CEN[ | IMDB-WIKI | 11 200 | 1.91 |
LRN[ | IMDB-WIKI | 2 800 | 1.90 | |
ORCNN[ | IMDB-WIKI | 479.7 | 3.27 | |
C3AE[ | IMDB-WIKI | 39.7 | 2.75 | |
SSR-Net[ | IMDB-WIKI | 40.9 | 3.16 | |
DenseNet[ | IMDB-WIKI | 242 | 5.05 | |
MobileNet[ | IMDB-WIKI | 226.3 | 6.50 | |
MPDNet | — | 175 | 2.67 |
Tab. 2 Comparison of experimental results on MORPH Ⅱ dataset
类型 | 方法 | 预训练集 | 参数量/103 | MAE |
---|---|---|---|---|
重量级 | DEX[ | ImageNet | 138 000 | 3.25 |
DEX[ | IMDB-WIKI | 138 000 | 2.68 | |
Posterior[ | — | 138 000 | 2.52 | |
MV[ | IMDB-WIKI | 138 000 | 2.16 | |
DLDL[ | IMDB-WIKI | 138 000 | 2.42 | |
RankingCNN[ | Audience | 500 000 | 2.96 | |
BridgeNet[ | IMDB-WIKI | 138 000 | 2.38 | |
DORFs[ | ImageNet | 138 000 | 2.19 | |
轻量级 | CEN[ | IMDB-WIKI | 11 200 | 1.91 |
LRN[ | IMDB-WIKI | 2 800 | 1.90 | |
ORCNN[ | IMDB-WIKI | 479.7 | 3.27 | |
C3AE[ | IMDB-WIKI | 39.7 | 2.75 | |
SSR-Net[ | IMDB-WIKI | 40.9 | 3.16 | |
DenseNet[ | IMDB-WIKI | 242 | 5.05 | |
MobileNet[ | IMDB-WIKI | 226.3 | 6.50 | |
MPDNet | — | 175 | 2.67 |
方法 | 参数λ | MAE |
---|---|---|
回归 | 0 | 2.83 |
MPD | 1 | 2.78 |
5 | 2.75 | |
10 | 2.70 | |
15 | 2.69 | |
17 | 2.70 | |
18 | 2.67 | |
20 | 2.71 | |
高斯分布 | — | 2.78 |
Tab. 3 Ablation experimental results of parameter λ
方法 | 参数λ | MAE |
---|---|---|
回归 | 0 | 2.83 |
MPD | 1 | 2.78 |
5 | 2.75 | |
10 | 2.70 | |
15 | 2.69 | |
17 | 2.70 | |
18 | 2.67 | |
20 | 2.71 | |
高斯分布 | — | 2.78 |
类型 | 方法 | 预训练集 | CS(3)/% | CS(5)/% |
---|---|---|---|---|
重量级 | Posterior[ | IMDB-WIKI | 62.1 | 80.4 |
Posterior[ | MS-Celeb | 64.2 | 82.2 | |
轻量级 | CEN[ | IMDB-WIKI | 63.7 | 82.9 |
LRN[ | IMDB-WIKI | 64.4 | 82.9 | |
SSR-Net[ | IMDB-WIKI | 54.9 | 74.1 | |
DenseNet[ | IMDB-WIKI | 51.7 | 69.4 | |
MobileNet[ | IMDB-WIKI | 44.0 | 60.6 | |
MPDNet | IMDB-WIKI | 61.1 | 81.2 |
Tab. 4 Comparison of experimental results on MegaAge-Asian dataset
类型 | 方法 | 预训练集 | CS(3)/% | CS(5)/% |
---|---|---|---|---|
重量级 | Posterior[ | IMDB-WIKI | 62.1 | 80.4 |
Posterior[ | MS-Celeb | 64.2 | 82.2 | |
轻量级 | CEN[ | IMDB-WIKI | 63.7 | 82.9 |
LRN[ | IMDB-WIKI | 64.4 | 82.9 | |
SSR-Net[ | IMDB-WIKI | 54.9 | 74.1 | |
DenseNet[ | IMDB-WIKI | 51.7 | 69.4 | |
MobileNet[ | IMDB-WIKI | 44.0 | 60.6 | |
MPDNet | IMDB-WIKI | 61.1 | 81.2 |
1 | 曹猛,田青,马廷淮,等. 人类面部属性估计研究:综述[J]. 软件学报, 2019, 30(7):2188-2207. 10.13328/j.cnki.jos.005837 |
CAO M, TIAN Q, MA T H, et al. Human facial attributes estimation: a survey[J]. Journal of Software, 2019, 30(7):2188-2207. 10.13328/j.cnki.jos.005837 | |
2 | HOU P, GENG X, HUO Z W, et al. Semi-supervised adaptive label distribution learning for facial age estimation[C]// Proceedings of the 31st AAAI Conference on Artificial Intelligence. Palo Alto, CA: AAAI Press, 2017: 2015-2021. 10.1609/aaai.v31i1.10822 |
3 | ZENG X S, HUANG J Y, DING C X, et al. Soft-ranking label encoding for robust facial age estimation[J]. IEEE Access, 2020, 8: 134209-134218. 10.1109/access.2020.3010815 |
4 | SIMONYAN K, ZISSERMAN A. Very deep convolutional networks for large-scale image recognition[EB/OL]. [2022-01-19].. |
5 | HE K M, ZHANG X Y, REN S Q, et al. Deep residual learning for image recognition[C]// Proceedings of the 2016 IEEE Conference on Computer Vision and Pattern Recognition. Piscataway: IEEE, 2016: 770-778. 10.1109/cvpr.2016.90 |
6 | ROTHE R, TIMOFTE R, VAN GOOK L. DEX: Deep EXpectation of apparent age from a single image[C]// Proceedings of the 2015 IEEE International Conference on Computer Vision Workshops. Piscataway: IEEE, 2015: 252-257. 10.1109/iccvw.2015.41 |
7 | ANTIPOV G, BACCOUCHE M, BERRANI S A, et al. Apparent age estimation from face images combining general and children-specialized deep learning models[C]// Proceedings of the 2016 IEEE Conference on Computer Vision and Pattern Recognition Workshops. Piscataway: IEEE, 2016: 801-809. 10.1109/cvprw.2016.105 |
8 | ZHANG K, GAO C, GUO L R, et al. Age group and gender estimation in the wild with deep RoR architecture[J]. IEEE Access, 2017, 5: 22492-22503. 10.1109/access.2017.2761849 |
9 | HUANG G, LIU Z, L van der MAATEN, et al. Densely connected convolutional networks[C]// Proceedings of the 2017 IEEE Conference on Computer Vision and Pattern Recognition. Piscataway: IEEE, 2017: 2261-2269. 10.1109/cvpr.2017.243 |
10 | HOWARD A G, ZHU M L, CHEN B, et al. MobileNets: efficient convolutional neural networks for mobile vision applications[EB/OL]. [2022-06-26].. 10.48550/arXiv.1704.04861 |
11 | HU C L, GAO J B, CHEN J J, et al. Fine-grained age estimation with multi-attention network[J]. IEEE Access, 2020, 8: 196013-196023. 10.1109/access.2020.3034801 |
12 | LIU X H, ZOU Y, KUANG H L, et al. Face image age estimation based on data augmentation and lightweight convolutional neural network[J]. Symmetry, 2020, 12(1): No.146. 10.3390/sym12010146 |
13 | YANG T Y, HUANG Y H, LIN Y Y, et al. SSR-Net: a compact soft stagewise regression network for age estimation[C]// Proceedings of the 27th International Joint Conference on Artificial Intelligence. California: ijcai.org, 2018: 1078-1084. 10.24963/ijcai.2018/150 |
14 | ZHANG C, LIU S C, XU X, et al. C3AE: exploring the limits of compact model for age estimation[C]// Proceedings of the 2019 IEEE/CVF Conference on Computer Vision and Pattern Recognition. Piscataway: IEEE, 2019: 12579-12588. 10.1109/cvpr.2019.01287 |
15 | LIU X, LI S X, KAN M N, et al. AgeNet: deeply learned regressor and classifier for robust apparent age estimation[C]// Proceedings of the 2015 IEEE International Conference on Computer Vision Workshops. Piscataway: IEEE, 2015: 258-266. 10.1109/iccvw.2015.42 |
16 | SZEGEDY C, LIU W, JIA Y Q, et al. Going deeper with convolutions[C]// Proceedings of the 2015 IEEE Conference on Computer Vision and Pattern Recognition. Piscataway: IEEE, 2015: 1-9. 10.1109/cvpr.2015.7298594 |
17 | 李大湘,马宣,任娅琼,等.基于深度代价敏感CNN的年龄估计算法[J].模式识别与人工智能,2020,33(2):176-181. |
LI D X, MA X, REN Y Q, et al. Age estimation algorithm based on deep cost sensitive CNN[J]. Pattern Recognition and Artificial Intelligence, 2020, 33(2):176-181. | |
18 | NIU Z X, ZHOU M, WANG L, et al. Ordinal regression with multiple output CNN for age estimation[C]// Proceedings of the 2016 IEEE Conference on Computer Vision and Pattern Recognition. Piscataway: IEEE, 2016: 4920-4928. 10.1109/cvpr.2016.532 |
19 | CHEN S X, ZHANG C J, DONG M, et al. Using Ranking-CNN for age estimation[C]// Proceedings of the 2017 IEEE Conference on Computer Vision and Pattern Recognition. Piscataway: IEEE, 2017: 742-751. 10.1109/cvpr.2017.86 |
20 | GAO B B, XING C, XIE C W, et al. Deep label distribution learning with label ambiguity[J]. IEEE Transactions on Image Processing, 2017, 26(6): 2825-2838. 10.1109/tip.2017.2689998 |
21 | GAO B B, LIU X X, ZHOU H Y, et al. Learning expectation of label distribution for facial age and attractiveness estimation[EB/OL]. (2021-12-31) [2022-06-26].. |
22 | 李睿钰,祝继华,刘新媛.考虑标记间协作的标记分布学习[J].软件学报,2022,33(2):539-554. |
LI R Y, ZHU J H, LIU X Y. Label distribution learning with collaboration among labels[J]. Journal of Software, 2022, 33(2):539-554. | |
23 | PAN H Y, HAN H, SHAN S G, et al. Mean-variance loss for deep age estimation from a face[C]// Proceedings of the 2018 IEEE/CVF Conference on Computer Vision and Pattern Recognition. Piscataway: IEEE, 2018: 5285-5294. 10.1109/cvpr.2018.00554 |
24 | 张钰,刘建伟,左信.多任务学习[J].计算机学报,2020,43(7):1340-1378. 10.11897/SP.J.1016.2020.01340 |
ZHANG Y, LIU J W, ZUO X. Survey of multi-task learning[J]. Chinese Journal of Computers, 2020, 43(7):1340-1378. 10.11897/SP.J.1016.2020.01340 | |
25 | HU C L, CHEN J J, ZUO X, et al. Gender-specific multi-task micro-expression recognition using pyramid CGBP-TOP feature[J]. Computer Modeling in Engineering and Sciences, 2019, 118(3): 547-559. 10.31614/cmes.2019.04032 |
26 | RANJAN R, PATEL V M, CHELLAPPA R. HyperFace: a deep multi-task learning framework for face detection, landmark localization, pose estimation, and gender recognition[J]. IEEE Transactions on Pattern Analysis and Machine Intelligence, 2019, 41(1): 121-135. 10.1109/tpami.2017.2781233 |
27 | LIU S K, JOHNS E, DAVISON A J. End-to-end multi-task learning with attention[C]// Proceedings of the 2019 IEEE/CVF Conference on Computer Vision and Pattern Recognition. Piscataway: IEEE, 2019: 1871-1880. 10.1109/cvpr.2019.00197 |
28 | TAN Z C, WAN J, LEI Z, et al. Efficient group-n encoding and decoding for facial age estimation[J]. IEEE Transactions on Pattern Analysis and Machine Intelligence, 2018, 40(11): 2610-2623. 10.1109/tpami.2017.2779808 |
29 | XING J L, LI K, HU W M, et al. Diagnosing deep learning models for high accuracy age estimation from a single image[J]. Pattern Recognition, 2017, 66: 106-116. 10.1016/j.patcog.2017.01.005 |
30 | YI D, LEI Z, LI S Z. Age estimation by multi-scale convolutional network[C]// Proceedings of the 2014 Asian Conference on Computer Vision, LNCS 9005. Cham: Springer, 2015: 144-158. |
31 | ZHANG H Y, ZHANG Y, GENG X. Practical age estimation using deep label distribution learning[J]. Frontiers of Computer Science, 2021, 15(3): No.153318. 10.1007/s11704-020-8272-4 |
32 | RICANEK K, TESAFAYE T. MORPH: a longitudinal image database of normal adult age-progression[C]// Proceedings of the 7th International Conference on Automatic Face and Gesture Recognition. Piscataway: IEEE, 2006: 341-345. 10.1109/fgr.2006.4 |
33 | ZHANG Y X, LIU L, LI C. Quantifying facial age by posterior of age comparisons[C]// Proceedings of the 2017 British Machine Vision Conference. Durham: BMVA Press, 2017: No.108. 10.5244/c.31.108 |
34 | LI P P, HU Y B, HE R, et al. A coupled evolutionary network for age estimation[EB/OL]. [2022-03-26].. |
35 | LI P P, HU Y B, WU X, et al. Deep label refinement for age estimation[J]. Pattern Recognition, 2020, 100: No.107178. 10.1016/j.patcog.2019.107178 |
36 | LI W H, LU J W, FENG J J, et al. BridgeNet: a continuity-aware probabilistic network for age estimation[C]// Proceedings of the 2019 IEEE/CVF Conference on Computer Vision and Pattern Recognition. Piscataway: IEEE, 2019: 1145-1154. 10.1109/cvpr.2019.00124 |
37 | SHEN W, GUO Y L, WANG Y, et al. Deep regression forests for age estimation[C]// Proceedings of the 2018 IEEE/CVF Conference on Computer Vision and Pattern Recognition. Piscataway: IEEE, 2018: 2304-2313. 10.1109/cvpr.2018.00245 |
