Journal of Computer Applications ›› 2022, Vol. 42 ›› Issue (5): 1431-1439.DOI: 10.11772/j.issn.1001-9081.2021030464
Special Issue: 人工智能
• Artificial intelligence • Previous Articles Next Articles
Zhen QU, Kunting LI, Zhixi FENG()
Received:
2021-03-26
Revised:
2021-07-16
Accepted:
2021-07-16
Online:
2022-06-11
Published:
2022-05-10
Contact:
Zhixi FENG
About author:
QU Zhen, born in 2000. His research interests include machinelearning,remote sensing image processing.Supported by:
通讯作者:
冯志玺
作者简介:
屈震(2000—),男,陕西榆林人,主要研究方向:机器学习、遥感图像处理基金资助:
CLC Number:
Zhen QU, Kunting LI, Zhixi FENG. Remote sensing image scene classification based on effective channel attention[J]. Journal of Computer Applications, 2022, 42(5): 1431-1439.
屈震, 李堃婷, 冯志玺. 基于有效通道注意力的遥感图像场景分类[J]. 《计算机应用》唯一官方网站, 2022, 42(5): 1431-1439.
Add to citation manager EndNote|Ris|BibTeX
URL: https://www.joca.cn/EN/10.11772/j.issn.1001-9081.2021030464
网络 | 平均准确率/% | 每周期平均耗时/s | 参数量/106 | t/min |
---|---|---|---|---|
VGGNet16 | 60.01±0.12 | 15.32 | 138.0 | — |
ResNet50 | 79.53±0.10 | 13.21 | 25.5 | 24.40 |
ResNeXt50 | 81.22±0.08 | 14.31 | 25.0 | 5.31 |
SE-ResNeXt50 | 90.15±0.15 | 12.15 | 35.7 | 5.76 |
ECA-ResNeXt-8 | 93.86±0.12 | 10.28 | 22.8 | 1.01 |
Tab. 1 Result comparison of different indicators of different networks
网络 | 平均准确率/% | 每周期平均耗时/s | 参数量/106 | t/min |
---|---|---|---|---|
VGGNet16 | 60.01±0.12 | 15.32 | 138.0 | — |
ResNet50 | 79.53±0.10 | 13.21 | 25.5 | 24.40 |
ResNeXt50 | 81.22±0.08 | 14.31 | 25.0 | 5.31 |
SE-ResNeXt50 | 90.15±0.15 | 12.15 | 35.7 | 5.76 |
ECA-ResNeXt-8 | 93.86±0.12 | 10.28 | 22.8 | 1.01 |
分类器 | 准确率/% | 最后一层的平均训练时间/s |
---|---|---|
ECA-ResNeXt-8+Fully Connected | 93.86±0.12 | — |
ECA-ResNeXt-8+KNN | 89.22±0.22 | 5.5 |
ECA-ResNeXt-8+Naive Bayes | 91.93±0.10 | 10.2 |
ECA-ResNeXt-8+Random Forest | 87.52±0.15 | 11.4 |
ECA-ResNeXt-8+SVM | 95.81±0.12 | 15.8 |
Tab. 2 Performance comparison under different classifiers
分类器 | 准确率/% | 最后一层的平均训练时间/s |
---|---|---|
ECA-ResNeXt-8+Fully Connected | 93.86±0.12 | — |
ECA-ResNeXt-8+KNN | 89.22±0.22 | 5.5 |
ECA-ResNeXt-8+Naive Bayes | 91.93±0.10 | 10.2 |
ECA-ResNeXt-8+Random Forest | 87.52±0.15 | 11.4 |
ECA-ResNeXt-8+SVM | 95.81±0.12 | 15.8 |
数据集 | 图片总数 | 场景类别数 | 平均准确率/% |
---|---|---|---|
UC Merced-Land-Use | 2 100 | 21 | 95.81±0.12 |
KSA | 3 250 | 13 | 93.33±0.21 |
AID | 10 000 | 30 | 94.12±0.14 |
Optimal-31 | 1 860 | 31 | 92.41±0.16 |
WHU-RS19 | 1 005 | 19 | 93.56±0.11 |
RSSCN7 | 2 800 | 7 | 94.44±0.08 |
Tab. 3 Test results of proposed model on different datasets
数据集 | 图片总数 | 场景类别数 | 平均准确率/% |
---|---|---|---|
UC Merced-Land-Use | 2 100 | 21 | 95.81±0.12 |
KSA | 3 250 | 13 | 93.33±0.21 |
AID | 10 000 | 30 | 94.12±0.14 |
Optimal-31 | 1 860 | 31 | 92.41±0.16 |
WHU-RS19 | 1 005 | 19 | 93.56±0.11 |
RSSCN7 | 2 800 | 7 | 94.44±0.08 |
1 | SINGH A. Review article digital change detection techniques using remotely-sensed data [J]. International Journal of Remote Sensing, 1989, 10(6): 989-1003. 10.1080/01431168908903939 |
2 | CHENG G, HAN J W, LU X Q. Remote sensing image scene classification: benchmark and state of the art [J]. Proceedings of the IEEE, 2017, 105(10): 1865-1883. 10.1109/jproc.2017.2675998 |
3 | CHENG G, XIE X X, HAN J W, et al. Remote sensing image scene classification meets deep learning: challenges, methods, benchmarks, and opportunities [J]. IEEE Journal of Selected Topics in Applied Earth Observations and Remote Sensing, 2020, 13: 3735-3756. 10.1109/jstars.2020.3005403 |
4 | ROGAN J, CHEN D M. Remote sensing technology for mapping and monitoring land-cover and land-use change [J]. Progress in Planning, 2004, 61(4): 301-325. 10.1016/s0305-9006(03)00066-7 |
5 | YANG Y, NEWSAM S. Bag-of-visual-words and spatial extensions for land-use classification [C]// Proceedings of the 2010 18th ACM SIGSPATIAL International Conference on Advances in Geographic Information Systems. New York: ACM, 2010: 270-279. 10.1145/1869790.1869829 |
6 | CHERIYADAT A M. Unsupervised feature learning for aerial scene classification [J]. IEEE Transactions on Geoscience and Remote Sensing, 2014, 52(1): 439-451. 10.1109/tgrs.2013.2241444 |
7 | ZHANG H, SONG H J, YU B C. Application of hyper spectral remote sensing for urban forestry monitoring in natural disaster zones [C]// Proceedings of the 2011 International Conference on Computer and Management. Piscataway: IEEE, 2011: 1-4. 10.1109/caman.2011.5778867 |
8 | SWAIN M J, BALLARD D H. Color indexing [J]. International Journal of Computer Vision, 1991, 7(1): 11-32. 10.1007/bf00130487 |
9 | BHAGAVATHY S, MANJUNATH B S. Modeling and detection of geospatial objects using texture motifs [J]. IEEE Transactions on Geoscience and Remote Sensing, 2006, 44(12): 3706-3715. 10.1109/tgrs.2006.881741 |
10 | YANG Y, NEWSAM S. Comparing SIFT descriptors and Gabor texture features for classification of remote sensed imagery [C]// Proceedings of the 2008 15th IEEE International Conference on Image Processing. Piscataway: IEEE, 2008: 1852-1855. 10.1109/icip.2008.4712139 |
11 | FAN J Y, CHEN T, LU S J. Unsupervised feature learning for land-use scene recognition [J]. IEEE Transactions on Geoscience and Remote Sensing, 2017, 55(4): 2250-2261. 10.1109/tgrs.2016.2640186 |
12 | TU B, ZHANG X F, KANG X D, et al. Hyperspectral image classification via fusing correlation coefficient and joint sparse representation [J]. IEEE Geoscience and Remote Sensing Letters, 2018, 15(3): 340-344. 10.1109/lgrs.2017.2787338 |
13 | LI H T, GU H Y, HAN Y S, et al. Object-oriented classification of high-resolution remote sensing imagery based on an improved colour structure code and a support vector machine [J]. International Journal of Remote Sensing, 2010, 31(6): 1453-1470. 10.1080/01431160903475266 |
14 | HU J, SHEN L, SUN G. Squeeze-and-excitation networks [C]// Proceedings of the 2018 IEEE/CVF Conference on Computer Vision and Pattern Recognition. Piscataway: IEEE, 2018: 7132-7141. 10.1109/cvpr.2018.00745 |
15 | PENATTI O A B, NOGUEIRA K, SANTOS J A DOS. Do deep features generalize from everyday objects to remote sensing and aerial scenes domains? [C]// Proceedings of the 2015 IEEE Conference on Computer Vision and Pattern Recognition Workshops. Piscataway: IEEE, 2015: 44-51. 10.1109/cvprw.2015.7301382 |
16 | CHENG G, YANG C Y, YAO X W, et al. When deep learning meets metric learning: remote sensing image scene classification via learning discriminative CNNs [J]. IEEE Transactions on Geoscience and Remote Sensing, 2018, 56(5): 2811-2821. 10.1109/tgrs.2017.2783902 |
17 | 李玉峰,林辉.基于CNN的多光谱遥感图像地物覆盖分类[J].微处理机,2019,40(1):43-48. 10.3969/j.issn.1002-2279.2019.01.010 |
LI Y F, LIN H. Multi-spectral remote sensing image classification of ground coverage based on CNN [J]. Microprocessors, 2019, 40(1): 43-48. 10.3969/j.issn.1002-2279.2019.01.010 | |
18 | XIE J, HE N J, FANG L Y, et al. Scale-free convolutional neural network for remote sensing scene classification [J]. IEEE Transactions on Geoscience and Remote Sensing, 2019, 57(9): 6916-6928. 10.1109/tgrs.2019.2909695 |
19 | 王鑫,李可,徐明君,等.改进的基于深度学习的遥感图像分类算法[J].计算机应用,2019,39(2):382-387. 10.11772/j.issn.1001-9081.2018061324 |
WANG X, LI K, XU M J, et al. Improved remote sensing image classification algorithm based on deep learning [J]. Journal of Computer Applications, 2019, 39(2): 382-387. 10.11772/j.issn.1001-9081.2018061324 | |
20 | LI E Z, XIA J S, DU P J, et al. Integrating multilayer features of convolutional neural networks for remote sensing scene classification [J]. IEEE Transactions on Geoscience and Remote Sensing, 2017, 55(10): 5653-5665. 10.1109/tgrs.2017.2711275 |
21 | 孟佳佳,王弢.基于深度残差网络的遥感数据分类[J].数字技术与应用,2019,37(1):99-101. |
MENG J J, WANG T. Remote sensing data classification based on deep residual network [J]. Digital Technology and Application, 2019, 37(1): 99-101. | |
22 | XIE S N, GIRSHICK R, DOLLÁR P, et al. Aggregated residual transformations for deep neural networks [C]// Proceedings of the 2017 IEEE Conference on Computer Vision and Pattern Recognition. Piscataway: IEEE, 2017: 5987-5995. 10.1109/cvpr.2017.634 |
23 | ZHANG G J, LU S J, ZHANG W. CAD-Net: a context-aware detection network for objects in remote sensing imagery [J]. IEEE Transactions on Geoscience and Remote Sensing, 2019, 57(12): 10015-10024. 10.1109/tgrs.2019.2930982 |
24 | SU Y Z, WU Y J, WANG M, et al. Semantic segmentation of high resolution remote sensing image based on batch-attention mechanism [C]// Proceedings of 2019 IEEE International Geoscience and Remote Sensing Symposium. Piscataway: IEEE, 2019: 3856-3859. 10.1109/igarss.2019.8898198 |
25 | QI X Q, LI K Q, LIU P K, et al. Deep attention and multi-scale networks for accurate remote sensing image segmentation [J]. IEEE Access, 2020, 8: 146627-146639. 10.1109/access.2020.3015587 |
26 | WANG Q, LIU S T, CHANUSSOT J, et al. Scene classification with recurrent attention of VHR remote sensing images [J]. IEEE Transactions on Geoscience and Remote Sensing, 2019, 57(2): 1155-1167. 10.1109/tgrs.2018.2864987 |
27 | WANG H N, MIAO Y Q, WANG H R, et al. Convolutional attention in ensemble with knowledge transferred for remote sensing image classification [J]. IEEE Geoscience and Remote Sensing Letters, 2019, 16(4): 643-647. 10.1109/lgrs.2018.2878350 |
28 | 边小勇,费雄君,穆楠.基于尺度注意力网络的遥感图像场景分类[J].计算机应用,2020,40(3):872-877. 10.11772/j.issn.1001-9081.2019071314 |
BIAN X Y, FEI X J, MU N. Remote sensing image scene classification based on scale-attention network [J]. Journal of Computer Applications, 2020, 40(3): 872-877. 10.11772/j.issn.1001-9081.2019071314 | |
29 | ZHANG C, WANG Q, LI X L. A multi-task architecture for remote sensing by joint scene classification and image quality assessment [C]// Proceedings of 2019 IEEE International Geoscience and Remote Sensing Symposium. Piscataway: IEEE, 2019: 10055-10058. 10.1109/igarss.2019.8898659 |
30 | WANG Q L, WU B G, ZHU P F, et al. ECA-Net: efficient channel attention for deep convolutional neural networks [C]// Proceedings of the 2020 IEEE/CVF Conference on Computer Vision and Pattern Recognition. Piscataway: IEEE, 2020: 11531-11539. 10.1109/cvpr42600.2020.01155 |
31 | SIMONYAN K, ZISSERMAN A. Very deep convolutional networks for large-scale image recognition [EB/OL]. [2021-02-15].. 10.5244/c.28.6 |
32 | HE K M, ZHANG X Y, REN S Q, et al. Deep residual learning for image recognition [C]// Proceedings of the 2016 IEEE Conference on Computer Vision and Pattern Recognition. Piscataway: IEEE, 2016: 770-778. 10.1109/cvpr.2016.90 |
33 | ZHANG M L, ZHOU Z H. ML-KNN: a lazy learning approach to multi-label learning [J]. Pattern Recognition, 2007, 40(7): 2038-2048. 10.1016/j.patcog.2006.12.019 |
34 | PAL M. Random forest classifier for remote sensing classification [J]. International Journal of Remote Sensing, 2005, 26(1): 217-222. 10.1080/01431160412331269698 |
35 | RISH I. An empirical study of the naive Bayes classifier [J]. Journal of Universal Computer Science, 2001, 1(2):127. |
36 | ALHICHRI H S. Remote sensing datasets [DS/OL]. [2020-12-01]. . 10.1109/igarss.2018.8518874 |
