Journal of Computer Applications ›› 2024, Vol. 44 ›› Issue (5): 1597-1604.DOI: 10.11772/j.issn.1001-9081.2023050692
Special Issue: 多媒体计算与计算机仿真
• Multimedia computing and computer simulation • Previous Articles Next Articles
Guijin HAN1, Xinyuan ZHANG1(), Wentao ZHANG2, Ya HUANG1
Received:
2023-06-01
Revised:
2023-08-18
Accepted:
2023-08-21
Online:
2023-08-28
Published:
2024-05-10
Contact:
Xinyuan ZHANG
About author:
HAN Guijin, born in 1978, Ph. D., associate professor. His research interests include image processing, computer vision.Supported by:
通讯作者:
张馨渊
作者简介:
韩贵金(1978—),男,河南濮阳人,副教授,博士,CCF会员,主要研究方向:图像处理、计算机视觉基金资助:
CLC Number:
Guijin HAN, Xinyuan ZHANG, Wentao ZHANG, Ya HUANG. Self-supervised image registration algorithm based on multi-feature fusion[J]. Journal of Computer Applications, 2024, 44(5): 1597-1604.
韩贵金, 张馨渊, 张文涛, 黄娅. 基于多特征融合的自监督图像配准算法[J]. 《计算机应用》唯一官方网站, 2024, 44(5): 1597-1604.
Add to citation manager EndNote|Ris|BibTeX
URL: https://www.joca.cn/EN/10.11772/j.issn.1001-9081.2023050692
算法 | ILSVRC2012测试集l | ILSVRC2012测试集2 | ||||||
---|---|---|---|---|---|---|---|---|
AMA/% | AEPE | MS/% | 计算时间/s | AMA/% | AEPE | MS/% | 计算时间/s | |
SIFT | 31.94 | 125.47 | 7.79 | 1.182 | 29.89 | 146.36 | 7.79 | 1.056 |
GMN | 54.08 | 32.46 | 18.36 | 1.016 | 42.58 | 46.52 | 18.36 | 0.981 |
PCA-GM | 62.15 | 29.37 | 21.46 | 1.134 | 53.42 | 32.26 | 21.46 | 1.079 |
OpenGlue | 89.55 | 16.32 | 24.89 | 0.703 | 83.97 | 22.47 | 25.89 | 0.686 |
COTR | 8.85 | 25.46 | 17.251 | 87.91 | 9.46 | 24.46 | 18.027 | |
COMMON | 89.43 | 7.99 | 26.54 | 1.388 | 82.44 | 10.27 | 25.81 | 1.752 |
ResMatch | 90.27 | 6.32 | 24.11 | 22.76 | ||||
SIRA-MFF | 95.18 | 0.206 | 93.26 | 7.26 | 0.197 |
Tab. 1 Results of different algorithms on ILSVRC2012 test sets
算法 | ILSVRC2012测试集l | ILSVRC2012测试集2 | ||||||
---|---|---|---|---|---|---|---|---|
AMA/% | AEPE | MS/% | 计算时间/s | AMA/% | AEPE | MS/% | 计算时间/s | |
SIFT | 31.94 | 125.47 | 7.79 | 1.182 | 29.89 | 146.36 | 7.79 | 1.056 |
GMN | 54.08 | 32.46 | 18.36 | 1.016 | 42.58 | 46.52 | 18.36 | 0.981 |
PCA-GM | 62.15 | 29.37 | 21.46 | 1.134 | 53.42 | 32.26 | 21.46 | 1.079 |
OpenGlue | 89.55 | 16.32 | 24.89 | 0.703 | 83.97 | 22.47 | 25.89 | 0.686 |
COTR | 8.85 | 25.46 | 17.251 | 87.91 | 9.46 | 24.46 | 18.027 | |
COMMON | 89.43 | 7.99 | 26.54 | 1.388 | 82.44 | 10.27 | 25.81 | 1.752 |
ResMatch | 90.27 | 6.32 | 24.11 | 22.76 | ||||
SIRA-MFF | 95.18 | 0.206 | 93.26 | 7.26 | 0.197 |
算法 | AMA/% | AEPE/% | MS/% | 计算时间/s |
---|---|---|---|---|
SIFT | 30.27 | 137.42 | 7.79 | 1.160 |
GMN | 53.26 | 42.36 | 18.36 | 0.926 |
PCA-GM | 76.82 | 37.42 | 21.46 | 1.125 |
OpenGlue | 88.57 | 23.58 | 24.89 | 0.625 |
COTR | 91.25 | 24.91 | 18.367 | |
COMMON | 84.62 | 8.87 | 26.31 | 1.427 |
ResMatch | 82.03 | 38.91 | 16.84 | |
SIRA-MFF | 7.86 | 0.184 |
Tab. 2 Results of different algorithms on IMC-PT-SparseGM-50 test set
算法 | AMA/% | AEPE/% | MS/% | 计算时间/s |
---|---|---|---|---|
SIFT | 30.27 | 137.42 | 7.79 | 1.160 |
GMN | 53.26 | 42.36 | 18.36 | 0.926 |
PCA-GM | 76.82 | 37.42 | 21.46 | 1.125 |
OpenGlue | 88.57 | 23.58 | 24.89 | 0.625 |
COTR | 91.25 | 24.91 | 18.367 | |
COMMON | 84.62 | 8.87 | 26.31 | 1.427 |
ResMatch | 82.03 | 38.91 | 16.84 | |
SIRA-MFF | 7.86 | 0.184 |
Key.Net | DFE | 特征匹配 | EIL | AMA/% | |||
---|---|---|---|---|---|---|---|
32 | 128 | 256 | ED | PML | |||
√ | √ | 14.42 | |||||
√ | √ | 23.72 | |||||
√ | √ | 49.26 | |||||
√ | √ | 58.84 | |||||
√ | √ | 66.39 | |||||
√ | √ | √ | 89.69 |
Tab. 3 Ablation experiment results of direction descriptors with different channel numbers
Key.Net | DFE | 特征匹配 | EIL | AMA/% | |||
---|---|---|---|---|---|---|---|
32 | 128 | 256 | ED | PML | |||
√ | √ | 14.42 | |||||
√ | √ | 23.72 | |||||
√ | √ | 49.26 | |||||
√ | √ | 58.84 | |||||
√ | √ | 66.39 | |||||
√ | √ | √ | 89.69 |
算法 | 参数量/103 |
---|---|
PCA-GM | 1 471.0 |
OpenGlue | 940.0 |
COTR | 166.0 |
COMMON | 39.0 |
SIRA-MFF | 6.7 |
Tab. 4 Comparison of learnable parameter numbers in network feature extraction layers of different algorithms
算法 | 参数量/103 |
---|---|
PCA-GM | 1 471.0 |
OpenGlue | 940.0 |
COTR | 166.0 |
COMMON | 39.0 |
SIRA-MFF | 6.7 |
