Journal of Computer Applications ›› 2021, Vol. 41 ›› Issue (12): 3565-3570.DOI: 10.11772/j.issn.1001-9081.2021061034
Special Issue: 第十八届中国机器学习会议(CCML 2021)
• The 18th China Conference on Machine Learning • Previous Articles Next Articles
Received:
2021-05-12
Revised:
2021-07-18
Accepted:
2021-07-22
Online:
2021-12-28
Published:
2021-12-10
Contact:
Jing WEN
About author:
LI Qiang, born in 1995, M. S. candidate. His research interests include computer vision, image processing.
Supported by:
通讯作者:
温静
作者简介:
李强(1995—),男,山西大同人,硕士研究生,主要研究方向:计算机视觉、图像处理。
基金资助:
CLC Number:
Jing WEN, Qiang LI. Object tracking algorithm based on spatio-temporal context information enhancement[J]. Journal of Computer Applications, 2021, 41(12): 3565-3570.
温静, 李强. 基于时空上下文信息增强的目标跟踪算法[J]. 《计算机应用》唯一官方网站, 2021, 41(12): 3565-3570.
Add to citation manager EndNote|Ris|BibTeX
URL: https://www.joca.cn/EN/10.11772/j.issn.1001-9081.2021061034
算法 | 准确率 | 稳健性 | 预期平均重叠率 |
---|---|---|---|
DaSiamRPN | 0.61 | 0.22 | 0.411 |
SiamRPN | 0.56 | 0.26 | 0.344 |
ATOM | — | — | — |
SiamRPN++ | 0.64 | 0.20 | 0.464 |
SiamMask-box | 0.618 | 0.210 | 0.419 |
SiamMask-MBR | 0.621 | 0.210 | 0.421 |
SiamAsbm-box | 0.631 | 0.218 | 0.425 |
SiamAsbm-MBR | 0.661 | 0.214 | 0.434 |
Tab. 1 Experimental results on VOT2016 dataset
算法 | 准确率 | 稳健性 | 预期平均重叠率 |
---|---|---|---|
DaSiamRPN | 0.61 | 0.22 | 0.411 |
SiamRPN | 0.56 | 0.26 | 0.344 |
ATOM | — | — | — |
SiamRPN++ | 0.64 | 0.20 | 0.464 |
SiamMask-box | 0.618 | 0.210 | 0.419 |
SiamMask-MBR | 0.621 | 0.210 | 0.421 |
SiamAsbm-box | 0.631 | 0.218 | 0.425 |
SiamAsbm-MBR | 0.661 | 0.214 | 0.434 |
算法 | 准确率 | 稳健性 | 预期平均重叠率 |
---|---|---|---|
DaSiamRPN[ | 0.569 | 0.337 | 0.326 |
SiamRPN[ | 0.490 | 0.460 | 0.244 |
ATOM[ | 0.590 | 0.204 | 0.401 |
SiamRPN++[ | 0.600 | 0.234 | 0.414 |
SiamMask-box | 0.589 | 0.300 | 0.360 |
SiamMask-MBR[ | 0.592 | 0.286 | 0.359 |
SiamAsbm-box | 0.592 | 0.295 | 0.364 |
SiamAsbm-MBR | 0.629 | 0.258 | 0.370 |
Tab. 2 Experimental results on VOT2018 dataset
算法 | 准确率 | 稳健性 | 预期平均重叠率 |
---|---|---|---|
DaSiamRPN[ | 0.569 | 0.337 | 0.326 |
SiamRPN[ | 0.490 | 0.460 | 0.244 |
ATOM[ | 0.590 | 0.204 | 0.401 |
SiamRPN++[ | 0.600 | 0.234 | 0.414 |
SiamMask-box | 0.589 | 0.300 | 0.360 |
SiamMask-MBR[ | 0.592 | 0.286 | 0.359 |
SiamAsbm-box | 0.592 | 0.295 | 0.364 |
SiamAsbm-MBR | 0.629 | 0.258 | 0.370 |
Baseline基础上增加的模块 | 准确率 | 稳健性 | 预期平均重叠率 | ||
---|---|---|---|---|---|
特征叠加 | 特征对齐 | 特征增强 | |||
0.592 | 0.286 | 0.359 | |||
√ | 0.589 | 0.300 | 0.354 | ||
√ | √ | 0.579 | 0.272 | 0.360 | |
√ | √ | 0.610 | 0.290 | 0.355 | |
√ | √ | √ | 0.629 | 0.258 | 0.370 |
Tab. 3 Ablation experiment
Baseline基础上增加的模块 | 准确率 | 稳健性 | 预期平均重叠率 | ||
---|---|---|---|---|---|
特征叠加 | 特征对齐 | 特征增强 | |||
0.592 | 0.286 | 0.359 | |||
√ | 0.589 | 0.300 | 0.354 | ||
√ | √ | 0.579 | 0.272 | 0.360 | |
√ | √ | 0.610 | 0.290 | 0.355 | |
√ | √ | √ | 0.629 | 0.258 | 0.370 |
算法 | 区域相似度 | 轮廓精度 | 时间稳定性 | ||||
---|---|---|---|---|---|---|---|
JM | JO | JD | FM | FO | FD | TM | |
Msk[ | 0.792 | 0.924 | 0.094 | 0.749 | 0.864 | 0.093 | 0.222 |
Osvos[ | 0.797 | 0.933 | 0.151 | 0.806 | 0.922 | 0.155 | 0.348 |
SegFlow[ | 0.761 | 0.906 | 0.121 | 0.760 | 0.855 | 0.104 | 0.194 |
SiamMask[ | 0.712 | 0.862 | 0.051 | 0.663 | 0.759 | 0.073 | 0.279 |
本文算法 | 0.714 | 0.854 | 0.049 | 0.666 | 0.751 | 0.071 | 0.279 |
Tab. 4 Experimental results on DAVIS-2016 dataset
算法 | 区域相似度 | 轮廓精度 | 时间稳定性 | ||||
---|---|---|---|---|---|---|---|
JM | JO | JD | FM | FO | FD | TM | |
Msk[ | 0.792 | 0.924 | 0.094 | 0.749 | 0.864 | 0.093 | 0.222 |
Osvos[ | 0.797 | 0.933 | 0.151 | 0.806 | 0.922 | 0.155 | 0.348 |
SegFlow[ | 0.761 | 0.906 | 0.121 | 0.760 | 0.855 | 0.104 | 0.194 |
SiamMask[ | 0.712 | 0.862 | 0.051 | 0.663 | 0.759 | 0.073 | 0.279 |
本文算法 | 0.714 | 0.854 | 0.049 | 0.666 | 0.751 | 0.071 | 0.279 |
算法 | 区域相似度 | 轮廓精度 | 时间稳定性 | ||||
---|---|---|---|---|---|---|---|
JM | JO | JD | FM | FO | FD | TM | |
OnAVOS[ | 0.616 | 0.674 | 0.279 | 0.691 | 0.754 | 0.266 | 0.431 |
Osvos[ | 0.566 | 0.636 | 0.261 | 0.639 | 0.736 | 0.270 | 0.529 |
SiamMask[ | 0.534 | 0.628 | 0.193 | 0.585 | 0.675 | 0.209 | 0.451 |
本文算法 | 0.609 | 0.704 | 0.180 | 0.611 | 0.665 | 0.200 | 0.430 |
Tab. 5 Experimental results on DAVIS-2016 dataset
算法 | 区域相似度 | 轮廓精度 | 时间稳定性 | ||||
---|---|---|---|---|---|---|---|
JM | JO | JD | FM | FO | FD | TM | |
OnAVOS[ | 0.616 | 0.674 | 0.279 | 0.691 | 0.754 | 0.266 | 0.431 |
Osvos[ | 0.566 | 0.636 | 0.261 | 0.639 | 0.736 | 0.270 | 0.529 |
SiamMask[ | 0.534 | 0.628 | 0.193 | 0.585 | 0.675 | 0.209 | 0.451 |
本文算法 | 0.609 | 0.704 | 0.180 | 0.611 | 0.665 | 0.200 | 0.430 |
算法 | 速度 | 算法 | 速度 |
---|---|---|---|
Msk[ | 0.1 | SiamMask[ | 55 |
Osvos[ | 0.1 | 本文算法 | 32 |
Tab. 6 Speed analysis
算法 | 速度 | 算法 | 速度 |
---|---|---|---|
Msk[ | 0.1 | SiamMask[ | 55 |
Osvos[ | 0.1 | 本文算法 | 32 |
1 | MAKOVSKI T, VÁZQUEZ G A, JIANG Y V. Visual learning in multiple-object tracking[J]. PLoS ONE, 2008, 3(5): No.e2228. 10.1371/journal.pone.0002228 |
2 | HENRIQUES J F, CASEIRO R, MARTINS P, et al. High-speed tracking with kernelized correlation filters[J]. IEEE Transactions on Pattern Analysis and Machine Intelligence, 2015, 37(3): 583-596. 10.1109/tpami.2014.2345390 |
3 | DANELLJAN M, KHAN F S, FELSBERG M, et al. Adaptive color attributes for real-time visual tracking[C]// Proceedings of the 2014 IEEE Conference on Computer Vision and Pattern Recognition. Piscataway: IEEE, 2014: 1090-1097. 10.1109/cvpr.2014.143 |
4 | DANELLJAN M, ROBINSON A, KHAN F S, et al. Beyond correlation filters: learning continuous convolution operators for visual tracking[C]// Proceedings of the 2016 European Conference on Computer Vision, LNCS9909. Cham: Springer, 2016: 472-488. 10.3384/diss.diva-147543 |
5 | BERTINETTO L, VALMADRE J, HENRIQUES J F, et al. Fully-convolutional Siamese networks for object tracking[C]// Proceedings of the 2016 European Conference on Computer Vision, LNCS9914. Cham: Springer, 2016: 850-865. |
6 | LI B, YAN J J, WU W, et al. High performance visual tracking with Siamese region proposal network[C]// Proceedings of the 2018 IEEE/CVF Conference on Computer Vision and Pattern Recognition. Piscataway: IEEE, 2018: 8971-8980. 10.1109/cvpr.2018.00935 |
7 | WANG Q, ZHANG L, BERTINETTO L, et al. Fast online object tracking and segmentation: a unifying approach[C]// Proceedings of the 2019 IEEE/CVF Conference on Computer Vision and Pattern Recognition. Piscataway: IEEE, 2019: 1328-1338. 10.1109/cvpr.2019.00142 |
8 | GU X Q, CHANG H, MA B P, et al. Appearance-preserving 3D convolution for video-based person re-identification[C]// Proceedings of the 2020 European Conference on Computer Vision, LNCS12347. Cham: Springer, 2020: 228-243. |
9 | LAMPLE G, SABLAYROLLES A, RANZATO M, et al. Large memory layers with product keys[EB/OL]. (2019-12-16) [2021-03-20].. |
10 | ZHU Z, WANG Q, LI B, et al. Distractor-aware Siamese networks for visual object tracking[C]// Proceedings of the 2018 European Conference on Computer Vision, LNCS11213. Cham: Springer, 2018: 103-119. 10.1007/978-3-030-01240-3_7 |
11 | LI B, WU W, WANG Q, et al. SiamRPN++: evolution of Siamese visual tracking with very deep networks[C]// Proceedings of the 2019 IEEE/CVF Conference on Computer Vision and Pattern Recognition. Piscataway: IEEE, 2019: 4277-4286. 10.1109/cvpr.2019.00441 |
12 | DANELLJAN M, BHAT G, KHAN F S, et al. ATOM: accurate tracking by overlap maximization[C]// Proceedings of the 2019 IEEE/CVF Conference on Computer Vision and Pattern Recognition. Piscataway: IEEE, 2019: 4655-4664. 10.1109/cvpr.2019.00479 |
13 | HE K M, ZHANG X Y, REN S Q, et al. Deep residual learning for image recognition[C]// Proceedings of the 2016 IEEE Conference on Computer Vision and Pattern Recognition. Piscataway: IEEE, 2016: 770-778. 10.1109/cvpr.2016.90 |
14 | LIN T Y, MAIRE M, BELONGIE S, et al. Microsoft COCO: common objects in context[C]// Proceedings of the 2014 European Conference on Computer Vision, LNCS8693. Cham: Springer, 2014: 740-755. |
15 | RUSSAKOVSKY O, DENG J, SU H, et al. ImageNet large scale visual recognition challenge[J]. International Journal of Computer Vision, 2015, 115(3): 211-252. 10.1007/s11263-015-0816-y |
16 | XU N, YANG L J, FAN Y C, et al. YouTube-VOS: sequence-to-sequence video object segmentation[C]// Proceedings of the 2018 European Conference on Computer Vision, LNCS11209. Cham: Springer, 2018: 603-619. |
17 | KRISTAN M, LEONARDIS A, MATAS J, et al. The Visual Object Tracking VOT2016 challenge results[C]// Proceedings of the 2016 European Conference on Computer Vision, LNCS9914. Cham: Springer, 2016: 777-823. |
18 | KRISTAN M, LEONARDIS A, MATAS J, et al. The sixth Visual Object Tracking VOT2018 challenge results[C]// Proceedings of the 2018 European Conference on Computer Vision, LNCS11129. Cham: Springer, 2018: 3-53. |
19 | PERAZZI F, PONT-TUSET J, McWILLIAMS B, et al. A benchmark dataset and evaluation methodology for video object segmentation[C]// Proceedings of the 2016 IEEE Conference on Computer Vision and Pattern Recognition. Piscataway: IEEE, 2016: 724-732. 10.1109/cvpr.2016.85 |
20 | PONT-TUSET J, PERAZZI F, CAELLES S, et al. The 2017 DAVIS Challenge on Video Object Segmentation[EB/OL]. (2018-03-01) [2021-03-20].. |
21 | PERAZZI F, KHOREVA A, BENENSON R, et al. Learning video object segmentation from static images[C]// Proceedings of the 2017 IEEE Conference on Computer Vision and Pattern Recognition. Piscataway: IEEE, 2017: 3491-3500. 10.1109/cvpr.2017.372 |
22 | CAELLES S, MANINIS K K, PONT-TUSET J, et al. One-shot video object segmentation[C]// Proceedings of the 2017 IEEE Conference on Computer Vision and Pattern Recognition. Piscataway: IEEE, 2017: 5320-5329. 10.1109/cvpr.2017.565 |
23 | CHENG J C, TSAI Y H, WANG S J, et al. SegFlow: joint learning for video object segmentation and optical flow[C]// Proceedings of the 2017 IEEE International Conference on Computer Vision. Piscataway: IEEE, 2017: 686-695. 10.1109/iccv.2017.81 |
24 | VOIGTLAENDER P, LEIBE B. Online adaptation of convolutional neural networks for video object segmentation[C]// Proceedings of the 2017 British Machine Vision Conference. Durham: BMVA Press, 2017: No.116. 10.5244/c.31.116 |
