Journal of Computer Applications ›› 2024, Vol. 44 ›› Issue (5): 1579-1587.DOI: 10.11772/j.issn.1001-9081.2023050689
Special Issue: 多媒体计算与计算机仿真
• Multimedia computing and computer simulation • Previous Articles Next Articles
Lin GUO1,2,3, Kunhu LIU1(), Chenyang MA1, Youxue LAI1, Yingfen XU1
Received:
2023-06-01
Revised:
2023-09-01
Accepted:
2023-09-12
Online:
2023-09-14
Published:
2024-05-10
Contact:
Kunhu LIU
About author:
GUO Lin, born in 1978, Ph. D., associate professor. Her research interests include signal processing, machine vision, deep learning.Supported by:
郭琳1,2,3, 刘坤虎1(), 马晨阳1, 来佑雪1, 徐映芬1
通讯作者:
刘坤虎
作者简介:
郭琳(1978—),女,湖北随州人,副教授,博士,主要研究方向:信号处理、机器视觉、深度学习基金资助:
CLC Number:
Lin GUO, Kunhu LIU, Chenyang MA, Youxue LAI, Yingfen XU. Image super-resolution reconstruction based on residual attention network with receptive field expansion[J]. Journal of Computer Applications, 2024, 44(5): 1579-1587.
郭琳, 刘坤虎, 马晨阳, 来佑雪, 徐映芬. 基于感受野扩展残差注意力网络的图像超分辨率重建[J]. 《计算机应用》唯一官方网站, 2024, 44(5): 1579-1587.
Add to citation manager EndNote|Ris|BibTeX
URL: https://www.joca.cn/EN/10.11772/j.issn.1001-9081.2023050689
Input | RDAN1 | RDAN2 | RDAN3 | RDAN4 | Concat | Conv |
---|---|---|---|---|---|---|
64 | 64 | 64 | 64 | 64 | 256 | 64 |
Tab. 1 Number of channels in each layer of RF model
Input | RDAN1 | RDAN2 | RDAN3 | RDAN4 | Concat | Conv |
---|---|---|---|---|---|---|
64 | 64 | 64 | 64 | 64 | 256 | 64 |
SA | CA | Concatenate | Conv | ||||
---|---|---|---|---|---|---|---|
输入 | GN | Conv | 输入 | GAP | Conv1d | ||
32 | 32 | 32 | 32 | 32 | 32 | 64 | 64 |
Tab. 2 Number of channels in each layer of SCA model
SA | CA | Concatenate | Conv | ||||
---|---|---|---|---|---|---|---|
输入 | GN | Conv | 输入 | GAP | Conv1d | ||
32 | 32 | 32 | 32 | 32 | 32 | 64 | 64 |
尺度 | 模型 | Set5 | Set14 | BSD100 | Urban100 | ||||
---|---|---|---|---|---|---|---|---|---|
PSNR/dB | SSIM | PSNR/dB | SSIM | PSNR/dB | SSIM | PSNR/dB | SSIM | ||
×2 | Bicubic | 33.66 | 0.929 9 | 30.24 | 0.868 8 | 29.56 | 0.843 1 | 26.88 | 0.840 3 |
SRCNN[ | 36.66 | 0.954 2 | 32.45 | 0.906 7 | 31.36 | 0.887 9 | 29.50 | 0.894 6 | |
DRCN[ | 37.63 | 0.958 8 | 33.04 | 0.911 8 | 31.85 | 0.894 2 | 30.75 | 0.913 3 | |
SRFBN-S[ | 37.78 | 0.955 7 | 33.35 | 0.915 6 | 32.00 | 0.897 0 | 31.41 | 0.920 7 | |
CARN[ | 37.76 | 0.959 0 | 33.52 | 0.916 6 | 32.09 | 0.897 8 | 31.92 | 0.925 6 | |
RFDN[ | 38.05 | 0.960 6 | 33.68 | 0.918 4 | 32.16 | 0.899 4 | 32.12 | 0.927 8 | |
SwinIR[ | 38.14 | 0.961 1 | 33.86 | 0.920 6 | 32.31 | 0.901 2 | 32.76 | 0.934 0 | |
EDSR[ | 38.11 | 0.960 2 | 33.92 | 0.919 5 | 32.32 | 0.901 3 | 32.93 | 0.935 1 | |
RDN[ | 38.24 | 0.921 2 | 32.34 | 0.901 7 | 32.89 | 0.935 3 | |||
MHFN[ | — | — | 33.79 | 0.919 6 | 32.20 | 0.899 8 | 32.40 | 0.930 1 | |
ISRN[ | 0.961 3 | 33.84 | |||||||
本文RFE-RAN | 38.19 | 0.961 7 | 34.05 | 0.921 3 | 32.38 | 0.902 8 | 32.97 | 0.936 5 | |
×3 | Bicubic | 30.39 | 0.868 2 | 27.55 | 0.774 2 | 27.21 | 0.738 5 | 24.46 | 0.734 9 |
SRCNN[ | 32.75 | 0.909 0 | 29.30 | 0.821 5 | 28.41 | 0.786 3 | 26.24 | 0.798 9 | |
DRCN[ | 33.82 | 0.922 6 | 29.76 | 0.831 1 | 28.80 | 0.796 3 | 27.15 | 0.827 6 | |
SRFBN-S[ | 34.20 | 0.925 5 | 30.10 | 0.837 2 | 28.96 | 0.801 0 | 27.66 | 0.841 5 | |
CARN[ | 34.29 | 0.925 5 | 30.29 | 0.840 7 | 29.06 | 0.803 4 | 27.38 | 0.840 4 | |
RFDN[ | 34.41 | 0.927 3 | 30.34 | 0.842 0 | 29.09 | 0.805 0 | 28.21 | 0.852 5 | |
SwinIR[ | 34.62 | 0.928 9 | 30.54 | 0.846 3 | 29.20 | 0.808 2 | 28.66 | 0.862 4 | |
EDSR[ | 34.65 | 0.928 0 | 30.52 | 0.846 2 | 29.25 | 0.809 3 | 28.80 | 0.865 3 | |
RDN[ | 34.71 | 30.57 | 0.846 8 | 0.809 3 | 28.80 | 0.865 3 | |||
MHFN[ | — | — | 30.40 | 0.842 8 | 29.13 | 0.805 6 | 28.35 | 0.855 7 | |
ISRN[ | 0.929 4 | 29.25 | |||||||
本文RFE-RAN | 34.71 | 0.929 9 | 30.62 | 0.847 9 | 29.29 | 0.811 4 | 28.89 | 0.867 3 | |
×4 | Bicubic | 28.42 | 0.810 4 | 26.00 | 0.702 7 | 25.96 | 0.667 5 | 23.14 | 0.657 7 |
SRCNN[ | 30.48 | 0.862 8 | 27.50 | 0.751 3 | 26.90 | 0.710 1 | 24.52 | 0.722 1 | |
DRCN[ | 31.53 | 0.885 4 | 28.02 | 0.767 0 | 27.23 | 0.723 3 | 25.14 | 0.751 0 | |
SRFBN-S[ | 31.98 | 0.892 3 | 28.45 | 0.777 9 | 27.44 | 0.731 3 | 25.71 | 0.771 9 | |
CARN[ | 32.13 | 0.893 7 | 28.60 | 0.780 6 | 27.58 | 0.734 9 | 26.07 | 0.783 7 | |
RFDN[ | 32.24 | 0.895 2 | 28.61 | 0.781 9 | 27.57 | 0.736 0 | 26.11 | 0.785 8 | |
SwinIR[ | 32.44 | 0.897 6 | 28.77 | 0.785 8 | 27.69 | 0.740 6 | 26.47 | 0.798 0 | |
EDSR[ | 32.46 | 0.896 8 | 28.80 | 0.787 6 | 27.71 | 0.742 0 | |||
RDN[ | 32.47 | 0.899 0 | 0.787 1 | 27.72 | 0.741 9 | 26.61 | 0.802 8 | ||
MHFN[ | — | — | 28.66 | 0.783 0 | 27.61 | 0.737 1 | 26.27 | 0.790 9 | |
ISRN[ | 32.55 | 28.79 | |||||||
本文RFE-RAN | 0.899 7 | 28.82 | 0.787 6 | 27.75 | 0.743 9 | 26.71 | 0.805 2 |
Tab. 3 Comparison of average PSNR and SSIM values for comparison models on four experimental datasets
尺度 | 模型 | Set5 | Set14 | BSD100 | Urban100 | ||||
---|---|---|---|---|---|---|---|---|---|
PSNR/dB | SSIM | PSNR/dB | SSIM | PSNR/dB | SSIM | PSNR/dB | SSIM | ||
×2 | Bicubic | 33.66 | 0.929 9 | 30.24 | 0.868 8 | 29.56 | 0.843 1 | 26.88 | 0.840 3 |
SRCNN[ | 36.66 | 0.954 2 | 32.45 | 0.906 7 | 31.36 | 0.887 9 | 29.50 | 0.894 6 | |
DRCN[ | 37.63 | 0.958 8 | 33.04 | 0.911 8 | 31.85 | 0.894 2 | 30.75 | 0.913 3 | |
SRFBN-S[ | 37.78 | 0.955 7 | 33.35 | 0.915 6 | 32.00 | 0.897 0 | 31.41 | 0.920 7 | |
CARN[ | 37.76 | 0.959 0 | 33.52 | 0.916 6 | 32.09 | 0.897 8 | 31.92 | 0.925 6 | |
RFDN[ | 38.05 | 0.960 6 | 33.68 | 0.918 4 | 32.16 | 0.899 4 | 32.12 | 0.927 8 | |
SwinIR[ | 38.14 | 0.961 1 | 33.86 | 0.920 6 | 32.31 | 0.901 2 | 32.76 | 0.934 0 | |
EDSR[ | 38.11 | 0.960 2 | 33.92 | 0.919 5 | 32.32 | 0.901 3 | 32.93 | 0.935 1 | |
RDN[ | 38.24 | 0.921 2 | 32.34 | 0.901 7 | 32.89 | 0.935 3 | |||
MHFN[ | — | — | 33.79 | 0.919 6 | 32.20 | 0.899 8 | 32.40 | 0.930 1 | |
ISRN[ | 0.961 3 | 33.84 | |||||||
本文RFE-RAN | 38.19 | 0.961 7 | 34.05 | 0.921 3 | 32.38 | 0.902 8 | 32.97 | 0.936 5 | |
×3 | Bicubic | 30.39 | 0.868 2 | 27.55 | 0.774 2 | 27.21 | 0.738 5 | 24.46 | 0.734 9 |
SRCNN[ | 32.75 | 0.909 0 | 29.30 | 0.821 5 | 28.41 | 0.786 3 | 26.24 | 0.798 9 | |
DRCN[ | 33.82 | 0.922 6 | 29.76 | 0.831 1 | 28.80 | 0.796 3 | 27.15 | 0.827 6 | |
SRFBN-S[ | 34.20 | 0.925 5 | 30.10 | 0.837 2 | 28.96 | 0.801 0 | 27.66 | 0.841 5 | |
CARN[ | 34.29 | 0.925 5 | 30.29 | 0.840 7 | 29.06 | 0.803 4 | 27.38 | 0.840 4 | |
RFDN[ | 34.41 | 0.927 3 | 30.34 | 0.842 0 | 29.09 | 0.805 0 | 28.21 | 0.852 5 | |
SwinIR[ | 34.62 | 0.928 9 | 30.54 | 0.846 3 | 29.20 | 0.808 2 | 28.66 | 0.862 4 | |
EDSR[ | 34.65 | 0.928 0 | 30.52 | 0.846 2 | 29.25 | 0.809 3 | 28.80 | 0.865 3 | |
RDN[ | 34.71 | 30.57 | 0.846 8 | 0.809 3 | 28.80 | 0.865 3 | |||
MHFN[ | — | — | 30.40 | 0.842 8 | 29.13 | 0.805 6 | 28.35 | 0.855 7 | |
ISRN[ | 0.929 4 | 29.25 | |||||||
本文RFE-RAN | 34.71 | 0.929 9 | 30.62 | 0.847 9 | 29.29 | 0.811 4 | 28.89 | 0.867 3 | |
×4 | Bicubic | 28.42 | 0.810 4 | 26.00 | 0.702 7 | 25.96 | 0.667 5 | 23.14 | 0.657 7 |
SRCNN[ | 30.48 | 0.862 8 | 27.50 | 0.751 3 | 26.90 | 0.710 1 | 24.52 | 0.722 1 | |
DRCN[ | 31.53 | 0.885 4 | 28.02 | 0.767 0 | 27.23 | 0.723 3 | 25.14 | 0.751 0 | |
SRFBN-S[ | 31.98 | 0.892 3 | 28.45 | 0.777 9 | 27.44 | 0.731 3 | 25.71 | 0.771 9 | |
CARN[ | 32.13 | 0.893 7 | 28.60 | 0.780 6 | 27.58 | 0.734 9 | 26.07 | 0.783 7 | |
RFDN[ | 32.24 | 0.895 2 | 28.61 | 0.781 9 | 27.57 | 0.736 0 | 26.11 | 0.785 8 | |
SwinIR[ | 32.44 | 0.897 6 | 28.77 | 0.785 8 | 27.69 | 0.740 6 | 26.47 | 0.798 0 | |
EDSR[ | 32.46 | 0.896 8 | 28.80 | 0.787 6 | 27.71 | 0.742 0 | |||
RDN[ | 32.47 | 0.899 0 | 0.787 1 | 27.72 | 0.741 9 | 26.61 | 0.802 8 | ||
MHFN[ | — | — | 28.66 | 0.783 0 | 27.61 | 0.737 1 | 26.27 | 0.790 9 | |
ISRN[ | 32.55 | 28.79 | |||||||
本文RFE-RAN | 0.899 7 | 28.82 | 0.787 6 | 27.75 | 0.743 9 | 26.71 | 0.805 2 |
模型 | 参数量/MB | PSNR/dB | 模型 | 参数量/MB | PSNR/dB |
---|---|---|---|---|---|
EDSR | 43.08 | 32.32 | MHFN | 1.43 | 32.20 |
RDN | 22.30 | 32.34 | RFE-RAN | 15.63 | 32.38 |
ISRN | 3.50 | 32.35 |
Tab. 4 Number of parameters and PSNR of each model
模型 | 参数量/MB | PSNR/dB | 模型 | 参数量/MB | PSNR/dB |
---|---|---|---|---|---|
EDSR | 43.08 | 32.32 | MHFN | 1.43 | 32.20 |
RDN | 22.30 | 32.34 | RFE-RAN | 15.63 | 32.38 |
ISRN | 3.50 | 32.35 |
模型编号 | 模块数 | 参数量/MB | PSNR/dB | ||
---|---|---|---|---|---|
MM | RF | Set14 | Urban100 | ||
1 | 4 | 8 | 6.08 | 33.77 | 32.68 |
2 | 8 | 8 | 12.24 | 33.82 | 32.76 |
3 | 4 | 16 | 13.10 | 33.83 | 32.79 |
4 | 16 | 4 | 12.41 | 33.92 | 32.92 |
5 | 20 | 4 | 15.63 | 33.93 | 32.94 |
Tab. 5 Number of parameters and PSNR of model with different blocks
模型编号 | 模块数 | 参数量/MB | PSNR/dB | ||
---|---|---|---|---|---|
MM | RF | Set14 | Urban100 | ||
1 | 4 | 8 | 6.08 | 33.77 | 32.68 |
2 | 8 | 8 | 12.24 | 33.82 | 32.76 |
3 | 4 | 16 | 13.10 | 33.83 | 32.79 |
4 | 16 | 4 | 12.41 | 33.92 | 32.92 |
5 | 20 | 4 | 15.63 | 33.93 | 32.94 |
模型编号 | CA | SA | RFE | PSNR/dB |
---|---|---|---|---|
1 | × | × | × | 30.21 |
2 | √ | × | × | 30.16 |
3 | × | √ | × | 30.28 |
4 | √ | √ | × | 30.37 |
Tab. 6 Ablation experiment results
模型编号 | CA | SA | RFE | PSNR/dB |
---|---|---|---|---|
1 | × | × | × | 30.21 |
2 | √ | × | × | 30.16 |
3 | × | √ | × | 30.28 |
4 | √ | √ | × | 30.37 |
数据集 | 尺度 | RAN | RFE-RAN | ||
---|---|---|---|---|---|
PSNR/dB | SSIM | PSNR/dB | SSIM | ||
Set5 | ×2 | 38.15 | 0.961 6 | 38.19 | 0.961 7 |
×3 | 34.68 | 0.929 7 | 34.71 | 0.929 9 | |
×4 | 32.53 | 0.899 9 | 32.54 | 0.899 7 | |
Set14 | ×2 | 33.93 | 0.921 2 | 34.05 | 0.921 3 |
×3 | 30.55 | 0.846 6 | 30.62 | 0.847 9 | |
×4 | 28.81 | 0.787 4 | 28.82 | 0.787 6 | |
BSD100 | ×2 | 32.29 | 0.901 7 | 32.38 | 0.902 8 |
×3 | 29.26 | 0.810 5 | 29.29 | 0.811 4 | |
×4 | 27.72 | 0.742 6 | 27.75 | 0.743 9 | |
Urban100 | ×2 | 32.73 | 0.933 7 | 32.97 | 0.936 5 |
×3 | 28.77 | 0.864 1 | 28.89 | 0.867 3 | |
×4 | 26.60 | 0.801 2 | 26.70 | 0.805 2 |
Tab. 7 Influence of RFE module to proposed model on different datasets
数据集 | 尺度 | RAN | RFE-RAN | ||
---|---|---|---|---|---|
PSNR/dB | SSIM | PSNR/dB | SSIM | ||
Set5 | ×2 | 38.15 | 0.961 6 | 38.19 | 0.961 7 |
×3 | 34.68 | 0.929 7 | 34.71 | 0.929 9 | |
×4 | 32.53 | 0.899 9 | 32.54 | 0.899 7 | |
Set14 | ×2 | 33.93 | 0.921 2 | 34.05 | 0.921 3 |
×3 | 30.55 | 0.846 6 | 30.62 | 0.847 9 | |
×4 | 28.81 | 0.787 4 | 28.82 | 0.787 6 | |
BSD100 | ×2 | 32.29 | 0.901 7 | 32.38 | 0.902 8 |
×3 | 29.26 | 0.810 5 | 29.29 | 0.811 4 | |
×4 | 27.72 | 0.742 6 | 27.75 | 0.743 9 | |
Urban100 | ×2 | 32.73 | 0.933 7 | 32.97 | 0.936 5 |
×3 | 28.77 | 0.864 1 | 28.89 | 0.867 3 | |
×4 | 26.60 | 0.801 2 | 26.70 | 0.805 2 |
1 | YANG J, WRIGHT J, HUANG T S, et al. Image super-resolution via sparse representation[J]. IEEE Transactions on Image Processing, 2010, 19(11): 2861-2873. 10.1109/tip.2010.2050625 |
2 | TIMOFTE R, DE SMET V, VAN GOOL L. A+: adjusted anchored neighborhood regression for fast super-resolution[C]// Proceedings of 12th Asian Conference on Computer Vision. Cham: Springer, 2014: 111-126. 10.1007/978-3-319-16817-3_8 |
3 | DONG C, LOY C C, HE K, et al. Image super-resolution using deep convolutional networks[J]. IEEE Transaction on Pattern Analysis and Machine Intelligence, 2016, 38(2): 295-307. 10.1109/tpami.2015.2439281 |
4 | KIM J, LEE J K, LEE K M. Accurate image super-resolution using very deep convolutional networks[C]// Proceedings of the 2016 IEEE Conference on Computer Vision and Pattern Recognition. Piscataway: IEEE, 2016: 1646-1654. 10.1109/cvpr.2016.182 |
5 | KIM J, LEE J K, LEE K M. Deeply-recursive convolutional network for image super-resolution[C]// Proceedings of the 2016 IEEE Conference on Computer Vision and Pattern Recognition. Piscataway: IEEE, 2016: 1637-1645. 10.1109/cvpr.2016.181 |
6 | QU Y, LIN L, SHEN F, et al. Joint hierarchical category structure learning and large-scale image classification[J]. IEEE Transactions on Image Processing, 2017, 26(9): 4331-4346. 10.1109/tip.2016.2615423 |
7 | HE K, ZHANG X, REN S, et al. Delving deep into rectifiers: surpassing human-level performance on ImageNet classification [C]// Proceedings of the 2015 IEEE International Conference on Computer Vision. Piscataway: IEEE, 2015: 1026-1034. 10.1109/iccv.2015.123 |
8 | LAI W-S, HUANG J-B, NARENDRA A, et al. Deep Laplacian pyramid networks for fast and accurate super-resolution[C]// Proceedings of the 2017 IEEE Conference on Computer Vision and Pattern Recognition. Piscataway: IEEE, 2017: 5835-5843. 10.1109/cvpr.2017.618 |
9 | LIM B, SON S, KIM H, et al. Enhanced deep residual networks for single image super-resolution[C]// Proceedings of the 2017 IEEE Conference on Computer Vision and Pattern Recognition Workshops. Piscataway: IEEE, 2017: 1132-1140. 10.1109/cvprw.2017.151 |
10 | AHN N, KANG B, K-A SOHN. Fast, accurate, and lightweight super-resolution with cascading residual network[C]// Proceedings of the 15th European Conference on Computer Vision. Berlin: Springer, 2018: 256-272. 10.1007/978-3-030-01249-6_16 |
11 | ZHANG Y, LI K, LI K, et al. Image super-resolution using very deep residual channel attention networks[C]// Proceedings of the 15th European Conference on Computer Vision. Berlin: Springer, 2018: 286-301. 10.1007/978-3-030-01234-2_18 |
12 | ZHANG Y L, TIAN Y, KONG Y, et al. Residual dense network for image super-resolution[C]// Proceedings of the 2019 IEEE/CVF Conference on Computer Vision and Pattern Recognition. Piscataway: IEEE, 2019: 2472-2481. 10.1109/cvpr.2018.00262 |
13 | 王汇丰, 徐岩, 魏一铭, 等. 基于并联卷积与残差网络的图像超分辨率重建[J]. 计算机应用, 2022, 42(5): 1570-1576. 10.11772/j.issn.1001-9081.2021050742 |
WANG H F, XU Y, WEI Y M, et al. Image super-resolution reconstruction based on parallel convolution and residual network[J]. Journal of Computer Applications, 2022, 42(5): 1570-1576. 10.11772/j.issn.1001-9081.2021050742 | |
14 | 申利华, 李波. 基于特征金字塔网络和密集网络的肺部CT图像超分辨率重建[J]. 计算机应用, 2023, 43(5):1612-1619. 10.11772/j.issn.1001-9081.2022040620 |
SHEN L H, LI B. Super-resolution reconstruction of lung CT images based on feature pyramid network and dense network[J]. Journal of Computer Applications, 2023, 43(5):1612-1619. 10.11772/j.issn.1001-9081.2022040620 | |
15 | LI Z, YANG J, LIU Z, et al. Feedback network for image super-resolution[C]// Proceedings of the 2019 IEEE/CVF Conference on Computer Vision and Pattern Recognition. Piscataway: IEEE, 2019: 3862-3871. 10.1109/cvpr.2019.00399 |
16 | 李金新,黄志勇,李文斌,等. 基于多层次特征融合的图像超分辨率重建[J]. 自动化学报,2023,49(1): 161-171. |
LI J X, HUANG Z Y, LI W B, et al. Image super-resolution based on multi-level feature fusion [J]. Acta Automatica Sinica, 2023,49(1): 161-171. | |
17 | LIU Y, WANG S, ZHANG J, et al. Iterative network for image super-resolution [J]. IEEE Transaction on Multimedia, 2022, 24: 2259-2272. 10.1109/tmm.2021.3078615 |
18 | SHI W, CABALLERO J, HUSZÁR F, et al. Real-time single image and video super-resolution using an efficient sub-pixel convolutional neural network[C]// Proceedings of the 2016 IEEE Conference on Computer Vision and Pattern Recognition. Piscataway: IEEE, 2016: 1874-1883. 10.1109/cvpr.2016.207 |
19 | HU J, SHEN L, SUN G. Squeeze-and-excitation networks[C]// Proceedings of the 2018 IEEE/CVF Conference on Computer Vision and Pattern Recognition. Piscataway: IEEE, 2018: 7132-7141. 10.1109/cvpr.2018.00745 |
20 | LIU J, TANG J, WU G. Residual feature distillation network for lightweight image super-resolution[C]// Proceedings of the 16th European Conference on Computer Vision. Berlin: Springer, 2020: 41- 55. 10.1007/978-3-030-67070-2_2 |
21 | LIANG J, CAO J, SUN G, et al. SwinIR: image restoration using Swin Transformer[C]// Proceedings of the 2021 IEEE/CVF International Conference on Computer Vision. Piscataway: IEEE, 2021: 1833-1844. 10.1109/iccvw54120.2021.00210 |
[1] | Jing QIN, Zhiguang QIN, Fali LI, Yueheng PENG. Diagnosis of major depressive disorder based on probabilistic sparse self-attention neural network [J]. Journal of Computer Applications, 2024, 44(9): 2970-2974. |
[2] | Xiyuan WANG, Zhancheng ZHANG, Shaokang XU, Baocheng ZHANG, Xiaoqing LUO, Fuyuan HU. Unsupervised cross-domain transfer network for 3D/2D registration in surgical navigation [J]. Journal of Computer Applications, 2024, 44(9): 2911-2918. |
[3] | Liting LI, Bei HUA, Ruozhou HE, Kuang XU. Multivariate time series prediction model based on decoupled attention mechanism [J]. Journal of Computer Applications, 2024, 44(9): 2732-2738. |
[4] | Hang YANG, Wanggen LI, Gensheng ZHANG, Zhige WANG, Xin KAI. Multi-layer information interactive fusion algorithm based on graph neural network for session-based recommendation [J]. Journal of Computer Applications, 2024, 44(9): 2719-2725. |
[5] | Yunchuan HUANG, Yongquan JIANG, Juntao HUANG, Yan YANG. Molecular toxicity prediction based on meta graph isomorphism network [J]. Journal of Computer Applications, 2024, 44(9): 2964-2969. |
[6] | Shunyong LI, Shiyi LI, Rui XU, Xingwang ZHAO. Incomplete multi-view clustering algorithm based on self-attention fusion [J]. Journal of Computer Applications, 2024, 44(9): 2696-2703. |
[7] | Liehong REN, Lyuwen HUANG, Xu TIAN, Fei DUAN. Multivariate long-term series forecasting method with DFT-based frequency-sensitive dual-branch Transformer [J]. Journal of Computer Applications, 2024, 44(9): 2739-2746. |
[8] | Yexin PAN, Zhe YANG. Optimization model for small object detection based on multi-level feature bidirectional fusion [J]. Journal of Computer Applications, 2024, 44(9): 2871-2877. |
[9] | Zhiqiang ZHAO, Peihong MA, Xinhong HEI. Crowd counting method based on dual attention mechanism [J]. Journal of Computer Applications, 2024, 44(9): 2886-2892. |
[10] | Kaipeng XUE, Tao XU, Chunjie LIAO. Multimodal sentiment analysis network with self-supervision and multi-layer cross attention [J]. Journal of Computer Applications, 2024, 44(8): 2387-2392. |
[11] | Yuqing WANG, Guangli ZHU, Wenjie DUAN, Shuyu LI, Ruotong ZHOU. Sentiment classification model of psychological counseling text based on attention over attention mechanism [J]. Journal of Computer Applications, 2024, 44(8): 2393-2399. |
[12] | Pengqi GAO, Heming HUANG, Yonghong FAN. Fusion of coordinate and multi-head attention mechanisms for interactive speech emotion recognition [J]. Journal of Computer Applications, 2024, 44(8): 2400-2406. |
[13] | Tong CHEN, Fengyu YANG, Yu XIONG, Hong YAN, Fuxing QIU. Construction method of voiceprint library based on multi-scale frequency-channel attention fusion [J]. Journal of Computer Applications, 2024, 44(8): 2407-2413. |
[14] | Caiqin WANG, Yuhao ZHOU, Shunxiang ZHANG, Yanhui WANG, Xiaolong WANG. Aspect-opinion pair extraction of new energy vehicle complaint text based on context enhancement [J]. Journal of Computer Applications, 2024, 44(8): 2430-2436. |
[15] | Yuhan LIU, Genlin JI, Hongping ZHANG. Video pedestrian anomaly detection method based on skeleton graph and mixed attention [J]. Journal of Computer Applications, 2024, 44(8): 2551-2557. |
Viewed | ||||||
Full text |
|
|||||
Abstract |
|
|||||
