Forest pest detection method based on attention model and lightweight YOLOv4

doi:10.11772/j.issn.1001-9081.2021122164

Journal of Computer Applications ›› 2022, Vol. 42 ›› Issue (11): 3580-3587.DOI: 10.11772/j.issn.1001-9081.2021122164

Special Issue: 第二十一届中国虚拟现实大会

• ChinaVR 2021 • Previous Articles Next Articles

Forest pest detection method based on attention model and lightweight YOLOv4

Haiyan SUN, Yunbo CHEN, Dingwei FENG, Tong WANG, Xingquan CAI()

School of Information Science and Technology，North China University of Technology，Beijing 100144，China

Received:2021-12-24 Revised:2022-03-14 Accepted:2022-03-17 Online:2022-05-17 Published:2022-11-10
Contact: Xingquan CAI
About author:SUN Haiyan， born in 1980， Ph. D.， lecturer. Her research interests include virtual reality， deep learning.
CHEN Yunbo， born in 2001. Her research interests include virtual reality， deep learning.
FENG Dingwei， born in 1997， M. S. candidate. His research interests include virtual reality， deep learning.
WANG Tong， born in 1996， M. S. candidate. His research interests include virtual reality， deep learning.
CAI Xingquan， born in 1980， Ph. D.， professor. His research interests include virtual reality， human‑computer interaction， deep learning.
Supported by:
Beijing Social Science Foundation of China(20YTB011)

基于注意力模型和轻量化YOLOv4的林业害虫检测方法

孙海燕, 陈云博, 封丁惟, 王通, 蔡兴泉()

北方工业大学信息学院，北京 100144

通讯作者: 蔡兴泉
作者简介:孙海燕（1980—），女，山东济宁人，讲师，博士，主要研究方向：虚拟现实、深度学习
陈云博（2001—），女，河南郑州人，主要研究方向：虚拟现实、深度学习
封丁惟（1997—），男，山东青岛人，硕士研究生，主要研究方向：虚拟现实、深度学习
王通（1996—），男，山西大同人，硕士研究生，主要研究方向：虚拟现实、深度学习
蔡兴泉（1980—），男，山东济南人，教授，博士，CCF高级会员，主要研究方向：虚拟现实、人机互动、深度学习。xingquancai@126.com
基金资助:
北京市社会科学基金资助项目(20YTB011)

Abstract

Abstract:

Aiming at the problems of slow detection speed， low precision， missed detection and false detection of current forest pest detection methods， a forest pest detection method based on attention model and lightweight YOLOv4 was proposed. Firstly， a dataset was constructed and preprocessed by using geometric transformation， random color dithering and mosaic data augmentation techniques. Secondly， the backbone network of YOLOv4 was replaced with a lightweight network MobileNetV3， and the Convolutional Block Attention Module （CBAM） was added to the improved Path Aggregation Network （PANet） to build the improved lightweight YOLOv4 network. Thirdly， Focal Loss was introduced to optimize the loss function of the YOLOv4 network model. Finally， the preprocessed dataset was input into the improved network model， and the detection results containing pest species and location information were output. Experimental results show that all the improvements of the network contribute to the performance improvement of the model； compared with the original YOLOv4 model， the proposed model has faster detection speed and higher detection mean Average Precision （mAP）， and effectively solves the problem of missed detection and false detection. The proposed new model is superior to the existing mainstream network models and can meet the precision and speed requirements of real?time detection of forest pests.

Key words: forest pest detection, lightweight network, attention model, loss function

摘要：

针对当前林业害虫检测方法检测速度慢、准确率较低和存在漏检误检等问题，提出一种基于注意力模型和轻量化YOLOv4的林业害虫检测方法。首先构建数据集，使用几何变换、随机色彩抖动和Mosaic数据增强技术对数据集进行预处理；其次将YOLOv4的主干网络替换为轻量化网络MobileNetV3，并在改进后的路径聚合网络（PANet）中添加卷积块注意力模块（CBAM），搭建改进的轻量化YOLOv4网络模型；然后引入Focal Loss优化YOLOv4网络模型的损失函数；最后将预处理后的数据集输入到改进后的网络模型中，输出包含害虫种类和位置信息的检测结果。实验结果表明，该网络的各项改进点对模型的性能提升都有效；相较于原YOLOv4模型，新模型的检测速度更快，平均精度均值（mAP）更高，并且能有效解决漏检和误检问题。新模型优于目前的主流网络模型，能满足林业害虫实时检测的精度和速度要求。

关键词: 林业害虫检测, 轻量化网络, 注意力模型, 损失函数

CLC Number:

TP391.9

Haiyan SUN, Yunbo CHEN, Dingwei FENG, Tong WANG, Xingquan CAI. Forest pest detection method based on attention model and lightweight YOLOv4[J]. Journal of Computer Applications, 2022, 42(11): 3580-3587.

孙海燕, 陈云博, 封丁惟, 王通, 蔡兴泉. 基于注意力模型和轻量化YOLOv4的林业害虫检测方法[J]. 《计算机应用》唯一官方网站, 2022, 42(11): 3580-3587.

Figures/Tables 16

Tab. 1 Number statistics of samples of different species of pests

害虫种类	样本数量	害虫种类	样本数量
Boerner	2 232	armandi	2 346
Leconte	2 450	coleoptera	2 091
Linnaeus	1 860	linnaeus	1 967
acuminatus	1 604

Fig. 1 Examples of images augmented by geometric transformation

Fig. 2 Examples of images augmented by random color dithering

Fig. 3 Example images by Mosaic data augmentation

Fig. 4 MobileNetV3 network structure

Fig. 5 SPP module structure

Fig. 6 CBAM structure

Fig. 7 Structure of PANet introducing CBAM

Fig. 8 Network model structure of proposed method

Fig. 9 Annotation of pest image

Fig. 10 PR curves of seven species of pests

Tab. 2 Comparison of objective data of proposed model and original YOLOv4 model

模型	AP/%							mAP/%	帧率/FPS
模型	Boerner	Leconte	Linnaeus	acuminatus	armandi	coleoptera	linnaeus	mAP/%	帧率/FPS
YOLOv4	95.9	94.8	85.6	70.5	89.2	81.9	91.5	87.0	25
本文模型	99.7	98.6	90.1	84.0	95.0	91.1	97.5	93.7	56

Fig. 11 Comparison of visualization effect of proposed model and original YOLOv4 model

Tab. 3 Results of ablation experiments

MobileNetV3	轻量化 PANet	+CBAM	+Focal Loss	mAP/%	帧率/FPS
				87.0	25
􀳫				86.5	43
	􀳫			87.8	34
		􀳫		90.2	26
			􀳫	91.0	30
􀳫	􀳫	􀳫	􀳫	93.7	56

Tab. 4 Comparison of different attention mechanisms

注意力模块	mAP/%	帧率/FPS
无	87.0	25
+SE	87.8	25
+ECA	89.4	26
+CBAM	90.2	26

Tab. 5 Comparison of proposed model and other models

模型	mAP/%	帧率/FPS	模型	mAP/%	帧率/FPS
Faster‑RCNN	86.6	15	文献［13］模型	84.5	50
SSD	79.8	23	本文模型	93.7	56
YOLOv5	91.6	36

References 23

1	刘汉生. 陷阱式储粮害虫信息采集终端及其系统的研究与实现［D］. 北京：北京邮电大学， 2018.
	LIU H S. The research and implementation of the trap based information acquisition terminal and information system for stored grain pests［D］. Beijing： Beijing University of Posts and Telecommunications， 2018.
2	竺乐庆，张大兴，张真. 基于韦伯局部描述子和颜色直方图的鳞翅目昆虫翅图像特征描述与种类识别［J］. 昆虫学报， 2015， 58（4）： 419-426.
	ZHU L Q， ZHANG D X， ZHANG Z. Feature description of lepidopteran insect wing images based on WLD and HoC and its application in species recognition［J］. Acta Entomologica Sinica， 2015， 58（4）： 419-426.
3	GIRSHICK R. Fast R‑CNN［C］// Proceedings of the 2015 IEEE International Conference on Computer Vision. Piscataway： IEEE， 2015： 1440-1448. 10.1109/iccv.2015.169
4	REN S Q， HE K M， GIRSHICK R， et al. Faster R‑CNN： towards real‑time object detection with region proposal networks［C］// Proceedings of the 28th International Conference on Neural Information Processing Systems. Cambridge： MIT Press， 2015：91-99.
5	DAI J F， LI Y， HE K M， et al. R‑FCN： object detection via region‑based fully convolutional networks［C］// Proceedings of the 30th International Conference on Neural Information Processing Systems. Red Hook， NY： Curran Associates Inc.， 2016： 379-387.
6	LIN T Y， DOLLÁR P， GIRSHICK R， et al. Feature pyramid networks for object detection［C］// Proceedings of the 2017 IEEE Conference on Computer Vision and Pattern Recognition. Piscataway： IEEE， 2017： 936-944. 10.1109/cvpr.2017.106
7	REDMON J， DIVVALA S， GIRSHICK R， et al. You only look once： unified， real‑time object detection［C］// Proceedings of the 2016 IEEE Conference on Computer Vision and Pattern Recognition. Piscataway： IEEE， 2016： 779-788. 10.1109/cvpr.2016.91
8	REDMON J， FARHADI A. YOLO9000： better， faster， stronger［C］// Proceedings of the 2017 IEEE Conference on Computer Vision and Pattern Recognition. Piscataway： IEEE， 2017： 6517-6525. 10.1109/cvpr.2017.690
9	REDMON J， FARHADI A. YOLOv3： an incremental improvement［EB/OL］. （2018-04-08）［2021-12-10］.. 10.1109/cvpr.2017.690
10	BOCHKOVSKIY A， WANG C Y， LIAO H Y M. YOLOv4： optimal speed and accuracy of object detection［EB/OL］. （2020-04-23）［2021-11-05］..
11	LIU W， ANGUELOV D， ERHAN D， et al. SSD： single shot multiBox detector［C］// Proceedings of the 2016 European Conference on Computer Vision， LNCS 9905. Cham： Springer， 2016： 21-37.
12	苗海委，周慧玲. 基于深度学习的粘虫板储粮害虫图像检测算法的研究［J］. 中国粮油学报， 2019， 34（12）： 93-99. 10.3969/j.issn.1003-0174.2019.12.016
	MIAO H W， ZHOU H L. Detection of stored‑grain insects image on sticky board using deep learning［J］. Journal of the Chinese Cereals and Oils Association， 2019， 34（12）： 93-99. 10.3969/j.issn.1003-0174.2019.12.016
13	候瑞环，杨喜旺，王智超，等. 一种基于YOLOv4‑TIA的林业害虫实时检测方法［J］. 计算机工程， 2022， 48（4）： 255-261.
	HOU R H， YANG X W， WANG Z C， et al. A real‑time detection methods for forestry pests based on YOLOv4‑TIA［J］. Computer Engineering， 2022， 48（4）： 255-261.
14	袁哲明，袁鸿杰，言雨璇，等. 基于深度学习的轻量化田间昆虫识别及分类模型［J］. 吉林大学学报（工学版）， 2021， 51（3）： 1131-1139.
	YUAN Z M， YUAN H J， YAN Y X， et al. Automatic recognition and classification of field insects based on lightweight deep learning model［J］. Journal of Jilin University （Engineering and Technology Edition）， 2021， 51（3）： 1131-1139.
15	李启运，纪庆革，洪赛丁. FastFace：实时鲁棒的人脸检测算法［J］. 中国图象图形学报， 2019， 24（10）： 1761-1771. 10.11834/jig.180662
	LI Q Y， JI Q G， HONG S D. FastFace： a real‑time robust algorithm for face detection［J］. Journal of Image and Graphics， 2019， 24（10）： 1761-1771. 10.11834/jig.180662
16	IANDOLA F N， HAN S， MOSKEWICZ M W， et al. SqueezeNet： AlexNet‑level accuracy with 50x fewer parameters and< 0.5 MB model size［EB/OL］. （2016-11-04）［2021-11-22］..
17	HOWARD A G， ZHU M L， CHEN B， et al. MobileNets： efficient convolutional neural networks for mobile vision applications［EB/OL］. （2017-04-17）［2021-12-08］.. 10.48550/arXiv.1704.04861
18	SANDLER M， HOWARD A， ZHU M L， et al. MobileNetV2： inverted residuals and linear bottlenecks［C］// Proceedings of the 2018 IEEE/CVF Conference on Computer Vision and Pattern Recognition. Piscataway： IEEE， 2018： 4510-4520. 10.1109/cvpr.2018.00474
19	HOWARD A， SANDLER M， CHEN B， et al. Searching for MobileNetV3［C］// Proceedings of the 2019 IEEE/CVF International Conference on Computer Vision. Piscataway： IEEE， 2019： 1314-1324. 10.1109/iccv.2019.00140
20	ZHANG X Y， ZHOU X Y， LIN M X， et al. ShuffleNet： an extremely efficient convolutional neural network for mobile devices［C］// Proceedings of the 2018 IEEE/CVF Conference on Computer Vision and Pattern Recognition. Piscataway： IEEE， 2018： 6848-6856. 10.1109/cvpr.2018.00716
21	MA N N， ZHANG X Y， ZHENG H T， et al. ShuffleNet V2： practical guidelines for efficient CNN architecture design［C］// Proceedings of the 2018 European Conference on Computer Vision， LNCS 11218. Cham： Springer， 2018： 122-138.
22	HAN K， WANG Y H， TIAN Q， et al. GhostNet： more features from cheap operations［C］// Proceedings of the 2020 IEEE/CVF Conference on Computer Vision and Pattern Recognition. Piscataway： IEEE， 2020： 1577-1586. 10.1109/cvpr42600.2020.00165
23	WOO S， PARK J， LEE J Y， et al. CBAM： convolutional block attention module［C］// Proceedings of the 2018 European Conference on Computer Vision， LNCS 11211. Cham： Springer， 2018： 3-19.
