Journal of Computer Applications ›› 2023, Vol. 43 ›› Issue (8): 2593-2601.DOI: 10.11772/j.issn.1001-9081.2022060893
• Multimedia computing and computer simulation • Previous Articles Next Articles
Xueyu HUANG1,2, Huaiyu HE1, Huimin LIN1, Jinshui CHEN3,4()
Received:
2022-06-20
Revised:
2022-09-05
Accepted:
2022-09-09
Online:
2022-09-22
Published:
2023-08-10
Contact:
Jinshui CHEN
About author:
HUANG Xueyu, born in 1970, Ph. D., professor. His research interests include enterprise informatization, smart factory.Supported by:
通讯作者:
陈金水
作者简介:
黄学雨(1970—),男,江西赣州人,教授,博士,主要研究方向:企业信息化、智能工厂基金资助:
CLC Number:
Xueyu HUANG, Huaiyu HE, Huimin LIN, Jinshui CHEN. Classification and recognition method of copper alloy metallograph based on feature aggregation[J]. Journal of Computer Applications, 2023, 43(8): 2593-2601.
黄学雨, 贺怀宇, 林慧敏, 陈金水. 基于特征聚合的铜合金金相图分类识别方法[J]. 《计算机应用》唯一官方网站, 2023, 43(8): 2593-2601.
Add to citation manager EndNote|Ris|BibTeX
URL: https://www.joca.cn/EN/10.11772/j.issn.1001-9081.2022060893
数据集类型 | 不同成分的铜合金 | |||
---|---|---|---|---|
Cu-Cr-Zr | Cu-Fe | Cu-Fe-Cr | Cu-Fe-Mg | |
训练集 | 1 020 | 878 | 824 | 324 |
验证集 | 348 | 296 | 276 | 108 |
测试集 | 336 | 272 | 266 | 90 |
Tab. 1 Distribution of pre-processed dataset
数据集类型 | 不同成分的铜合金 | |||
---|---|---|---|---|
Cu-Cr-Zr | Cu-Fe | Cu-Fe-Cr | Cu-Fe-Mg | |
训练集 | 1 020 | 878 | 824 | 324 |
验证集 | 348 | 296 | 276 | 108 |
测试集 | 336 | 272 | 266 | 90 |
阶段 | 输出大小 | ResNet-CBAM |
---|---|---|
Stage0:Conv 1 | 224 | 3 |
Stage1:CBMA | 224 | 1 1 |
224 | 7 | |
Stage2:Conv2 | 224 | 3 |
Stage3:Conv3 | 112 | |
Stage4:Conv4 | 56 | |
Stage5:Conv5 | 28 | |
Stage6:CBMA | 28 | 1 1 |
28 | 7 | |
Stage7 | 1 | Average pool,1 024 -d fc |
Tab. 2 ResNet-CBAM network parameters
阶段 | 输出大小 | ResNet-CBAM |
---|---|---|
Stage0:Conv 1 | 224 | 3 |
Stage1:CBMA | 224 | 1 1 |
224 | 7 | |
Stage2:Conv2 | 224 | 3 |
Stage3:Conv3 | 112 | |
Stage4:Conv4 | 56 | |
Stage5:Conv5 | 28 | |
Stage6:CBMA | 28 | 1 1 |
28 | 7 | |
Stage7 | 1 | Average pool,1 024 -d fc |
模型 | accuracy | macro-P | macro-R | macro-F1 |
---|---|---|---|---|
ResNet50 | 95.746 | 96.151 | 95.324 | 95.735 |
ResNet101 | 96.784 | 97.025 | 97.375 | 97.199 |
DenseNet121 | 97.925 | 98.213 | 98.325 | 98.162 |
Xception | 96.887 | 97.174 | 96.875 | 97.024 |
ResNet-CBAM | 97.510 | 97.525 | 97.662 | 97.662 |
Tab. 3 Performance comparison of different convolutional neural network models on test set
模型 | accuracy | macro-P | macro-R | macro-F1 |
---|---|---|---|---|
ResNet50 | 95.746 | 96.151 | 95.324 | 95.735 |
ResNet101 | 96.784 | 97.025 | 97.375 | 97.199 |
DenseNet121 | 97.925 | 98.213 | 98.325 | 98.162 |
Xception | 96.887 | 97.174 | 96.875 | 97.024 |
ResNet-CBAM | 97.510 | 97.525 | 97.662 | 97.662 |
方法 | accuracy | macro-P | macro-R | macro-F1 |
---|---|---|---|---|
GLCM-KNN | 81.327 | 81.988 | 79.831 | 79.995 |
GLCM-DT | 73.236 | 73.804 | 72.788 | 73.144 |
GLCM-SVM | 92.738 | 93.714 | 93.234 | 93.412 |
Tab. 4 Performance comparison of different GLCM-based classification methods on test set
方法 | accuracy | macro-P | macro-R | macro-F1 |
---|---|---|---|---|
GLCM-KNN | 81.327 | 81.988 | 79.831 | 79.995 |
GLCM-DT | 73.236 | 73.804 | 72.788 | 73.144 |
GLCM-SVM | 92.738 | 93.714 | 93.234 | 93.412 |
方法 | accuracy | macro-P | macro-R | macro-F1 |
---|---|---|---|---|
ResNet50-KNN | 98.237 | 97.893 | 97.362 | 97.617 |
ResNet50-DT | 96.577 | 95.958 | 96.218 | 96.079 |
ResNet50-SVM | 98.340 | 98.412 | 98.178 | 98.278 |
ResNet101-KNN | 98.432 | 97.981 | 98.241 | 98.102 |
ResNet101-DT | 97.303 | 97.141 | 97.692 | 97.379 |
ResNet101-SVM | 98.651 | 98.114 | 98.235 | 98.171 |
ResNet-CBAM-KNN | 98.651 | 98.635 | 98.483 | 98.552 |
ResNet-CBAM-DT | 96.888 | 97.292 | 96.732 | 96.992 |
ResNet-CBAM-SVM | 98.444 | 98.445 | 98.441 | 98.440 |
DenseNet121-KNN | 98.548 | 98.313 | 98.313 | 98.408 |
DenseNet121-DT | 96.058 | 95.374 | 96.266 | 95.732 |
DenseNet121-SVM | 98.548 | 98.534 | 98.543 | 98.521 |
Xception-KNN | 98.029 | 97.272 | 98.289 | 97.742 |
Xception-DT | 96.680 | 96.450 | 95.893 | 96.130 |
Xception-SVM | 98.029 | 97.644 | 98.300 | 97.950 |
Tab. 5 Comparison of different classification methods based on convolutional features on test set
方法 | accuracy | macro-P | macro-R | macro-F1 |
---|---|---|---|---|
ResNet50-KNN | 98.237 | 97.893 | 97.362 | 97.617 |
ResNet50-DT | 96.577 | 95.958 | 96.218 | 96.079 |
ResNet50-SVM | 98.340 | 98.412 | 98.178 | 98.278 |
ResNet101-KNN | 98.432 | 97.981 | 98.241 | 98.102 |
ResNet101-DT | 97.303 | 97.141 | 97.692 | 97.379 |
ResNet101-SVM | 98.651 | 98.114 | 98.235 | 98.171 |
ResNet-CBAM-KNN | 98.651 | 98.635 | 98.483 | 98.552 |
ResNet-CBAM-DT | 96.888 | 97.292 | 96.732 | 96.992 |
ResNet-CBAM-SVM | 98.444 | 98.445 | 98.441 | 98.440 |
DenseNet121-KNN | 98.548 | 98.313 | 98.313 | 98.408 |
DenseNet121-DT | 96.058 | 95.374 | 96.266 | 95.732 |
DenseNet121-SVM | 98.548 | 98.534 | 98.543 | 98.521 |
Xception-KNN | 98.029 | 97.272 | 98.289 | 97.742 |
Xception-DT | 96.680 | 96.450 | 95.893 | 96.130 |
Xception-SVM | 98.029 | 97.644 | 98.300 | 97.950 |
方法 | accuracy | macro-P | macro-R | macro-F1 |
---|---|---|---|---|
GLCM+ResNet50-KNN | 98.237 | 97.760 | 97.706 | 97.732 |
GLCM+ResNet50-DT | 97.822 | 97.495 | 97.538 | 97.506 |
GLCM+ResNet50-SVM | 98.859 | 98.703 | 98.615 | 98.655 |
GLCM+ResNet101-KNN | 98.444 | 98.449 | 98.513 | 98.475 |
GLCM+ResNet101-DT | 96.058 | 95.426 | 95.823 | 95.580 |
GLCM+ResNet101-SVM | 98.859 | 98.819 | 98.619 | 98.712 |
GLCM+ResNet-CBAM-KNN | 98.652 | 98.055 | 98.853 | 98.441 |
GLCM+ResNet-CBAM-DT | 96.992 | 97.401 | 97.005 | 97.182 |
GLCM+ResNet-CBAM-SVM(本文方法) | 98.963 | 99.077 | 98.927 | 98.996 |
GLCM+DenseNet121-KNN | 98.652 | 98.794 | 98.637 | 98.700 |
GLCM+DenseNet121-DT | 95.954 | 96.498 | 96.394 | 96.361 |
GLCM+DenseNet121-SVM | 98.963 | 98.832 | 98.895 | 98.856 |
GLCM+Xception-KNN | 97.925 | 97.178 | 98.198 | 97.650 |
GLCM+Xception-DT | 97.199 | 96.691 | 97.291 | 96.979 |
GLCM+Xception-SVM | 98.029 | 97.644 | 98.300 | 97.950 |
Tab. 6 Performance comparison of different classification methods based on aggregated features on test set
方法 | accuracy | macro-P | macro-R | macro-F1 |
---|---|---|---|---|
GLCM+ResNet50-KNN | 98.237 | 97.760 | 97.706 | 97.732 |
GLCM+ResNet50-DT | 97.822 | 97.495 | 97.538 | 97.506 |
GLCM+ResNet50-SVM | 98.859 | 98.703 | 98.615 | 98.655 |
GLCM+ResNet101-KNN | 98.444 | 98.449 | 98.513 | 98.475 |
GLCM+ResNet101-DT | 96.058 | 95.426 | 95.823 | 95.580 |
GLCM+ResNet101-SVM | 98.859 | 98.819 | 98.619 | 98.712 |
GLCM+ResNet-CBAM-KNN | 98.652 | 98.055 | 98.853 | 98.441 |
GLCM+ResNet-CBAM-DT | 96.992 | 97.401 | 97.005 | 97.182 |
GLCM+ResNet-CBAM-SVM(本文方法) | 98.963 | 99.077 | 98.927 | 98.996 |
GLCM+DenseNet121-KNN | 98.652 | 98.794 | 98.637 | 98.700 |
GLCM+DenseNet121-DT | 95.954 | 96.498 | 96.394 | 96.361 |
GLCM+DenseNet121-SVM | 98.963 | 98.832 | 98.895 | 98.856 |
GLCM+Xception-KNN | 97.925 | 97.178 | 98.198 | 97.650 |
GLCM+Xception-DT | 97.199 | 96.691 | 97.291 | 96.979 |
GLCM+Xception-SVM | 98.029 | 97.644 | 98.300 | 97.950 |
方法 | accuracy | macro-P | macro-R | macro-F1 |
---|---|---|---|---|
冻结全部卷积层权值 | 94.605 | 94.925 | 93.875 | 94.397 |
微调部分卷积层权值 | 94.605 | 95.175 | 93.925 | 94.545 |
Tab. 7 Performance comparison of two methods in literature [11] on test set
方法 | accuracy | macro-P | macro-R | macro-F1 |
---|---|---|---|---|
冻结全部卷积层权值 | 94.605 | 94.925 | 93.875 | 94.397 |
微调部分卷积层权值 | 94.605 | 95.175 | 93.925 | 94.545 |
1 | 中国机械工程学会热处理学会. 热处理手册:第四卷 热处理质量控制和检验[M]. 4版. 北京:机械工业出版社, 2008: 126-266. |
Chinese Heat Treatment Society. Heat Treatment Handbook: Volume IV Quality Control and Inspection of Heat Treatment[M]. 4th ed. Beijing: China Machine Press, 2008: 126-266. | |
2 | 张宏伟. 基于图像分析的废杂铜熔炼过程控制[D]. 杭州:浙江大学, 2014:2-19. |
ZHANG H W. Image analysis-based control system of scrap copper smelting processes[D]. Hangzhou: Zhejiang University, 2014:2-19. | |
3 | KIM C W, KIM H G, SUK H G. A study on the composition determination of Cu alloys by image processing technology[J]. Solid State Phenomena, 2006, 116/117: 795-798. 10.4028/www.scientific.net/ssp.116-117.795 |
4 | ZHANG H W, GE Z Q, YUAN X F, et al. Rapid vision-based system for secondary copper content estimation[J]. Transactions of Nonferrous Metals Society of China, 2014, 24(8): 2665-2676. 10.1016/s1003-6326(14)63397-5 |
5 | LI H, YAN W J, LI Z X, et al. Numerical and experimental study of the hot cracking phenomena in 6061/7075 dissimilar aluminum alloy resistance spot welding[J]. Journal of Manufacturing Processes, 2022, 77: 794-808. 10.1016/j.jmapro.2022.04.001 |
6 | 丛明,卢长奇,刘冬,等. 基于Refine-ACTDD的铸件外观微小缺陷检测方法[J]. 计算机集成制造系统, 2022, 28(9):2815-2824. |
CONG M, LU C Q, LIU D, et al. Detection method for tiny defects in casting appearance based on Refine-ACTDD[J]. Computer Integrated Manufacturing Systems, 2022, 28(9):2815-2824. | |
7 | CHEN Q L, LI W, CHEN Z. Analysis of microstructure characteristics of high sulfur steel based on computer image processing technology[J]. Results in Physics, 2019, 12: 392-397. 10.1016/j.rinp.2018.10.037 |
8 | WANG M, YANG L, ZHAO Z B, et al. Intelligent prediction of wear location and mechanism using image identification based on improved Faster R-CNN model[J]. Tribology International, 2022, 169: No.107466. 10.1016/j.triboint.2022.107466 |
9 | LI Y F, LI S H. Deep learning based phase transformation model for the prediction of microstructure and mechanical properties of hot-stamped parts[J]. International Journal of Mechanical Sciences, 2022, 220: No.107134. 10.1016/j.ijmecsci.2022.107134 |
10 | FERNANDEZ-ZELAIA P, ROSSY A M, CAMPBELL Q, et al. Austenitic parent grain reconstruction in martensitic steel using deep learning[J]. Materials Characterization, 2022, 185: No.111759. 10.1016/j.matchar.2022.111759 |
11 | PAPA J P, NAKAMURA R Y M, DE ALBUQUERQUE V H C, et al. Computer techniques towards the automatic characterization of graphite particles in metallographic images of industrial materials[J]. Expert Systems with Applications, 2013, 40(2): 590-597. 10.1016/j.eswa.2012.07.062 |
12 | DeCOST B L, HOLM E A. A computer vision approach for automated analysis and classification of microstructural image data[J]. Computational Materials Science, 2015, 110: 126-133. 10.1016/j.commatsci.2015.08.011 |
13 | 张永志,辛全忠,王永亮,等. 基于迁移学习的钢金相组织分类与识别方法的研究[J]. 材料导报, 2021, 35(24): 24152-24157. 10.11896/cldb.20070022 |
ZHANG Y Z, XIN Q Z, WANG Y L, et al. Research on classification and recognition method of steel metallographic structure based on transfer learning[J]. Materials Reports, 2021, 35(24): 24152-24157. 10.11896/cldb.20070022 | |
14 | AZIMI S M, BRITZ D, ENGSTLER M, et al. Advanced steel microstructural classification by deep learning methods[J]. Scientific Reports, 2018, 8: No.2128. 10.1038/s41598-018-20037-5 |
15 | HUMEAU-HEURTIER A. Texture feature extraction methods: a survey[J]. IEEE Access, 2019, 7: 8975-9000. 10.1109/access.2018.2890743 |
16 | BRYNOLFSSON P, NILSSON D, TORHEIM T, et al. Haralick texture features from Apparent Diffusion Coefficient (ADC) MRI images depend on imaging and pre-processing parameters[J]. Scientific Reports, 2017, 7: No.4041. 10.1038/s41598-017-04151-4 |
17 | WEBEL J, GOLA J, BRITZ D, et al. A new analysis approach based on Haralick texture features for the characterization of microstructure on the example of low-alloy steels[J]. Materials Characterization, 2018, 144: 584-596. 10.1016/j.matchar.2018.08.009 |
18 | LIN T Y, DOLLÁR P, GIRSHICK R, et al. Feature pyramid networks for object detection[C]// Proceedings of the 2017 IEEE Conference on Computer Vision and Pattern Recognition. Piscataway: IEEE, 2017: 936-944. 10.1109/cvpr.2017.106 |
19 | 王志伟,普园媛,王鑫,等. 基于多特征融合的多尺度服装图像精准化检索[J]. 计算机学报, 2020, 43(4): 740-754. 10.11897/SP.J.1016.2020.00740 |
WANG Z W, PU Y Y, WANG X, et al. Accurate retrieval of multi-scale clothing images based on multi-feature fusion[J]. Chinese Journal of Computers, 2020, 43(4): 740-754. 10.11897/SP.J.1016.2020.00740 | |
20 | HARALICK R M, SHANMUGAM K, DINSTEIN I, et al. Textural features for image classification[J]. IEEE Transactions on Systems, Man, and Cybernetics, 1973, SMC-3(6): 610-621. 10.1109/tsmc.1973.4309314 |
21 | WOO S, PARK J, LEE J Y, et al. CBAM: convolutional block attention module[C]// Proceedings of the 2018 European Conference on Computer Vision, LNCS 11211. Cham: Springer, 2018: 3-19. |
