Journal of Computer Applications ›› 2023, Vol. 43 ›› Issue (5): 1401-1408.DOI: 10.11772/j.issn.1001-9081.2022040581
Special Issue: 人工智能
• Artificial intelligence • Previous Articles Next Articles
Bin WANG1,2(), Tian XIANG1, Yidong LYU1, Xiaofan WANG1
Received:
2022-04-24
Revised:
2022-06-19
Accepted:
2022-07-01
Online:
2022-07-26
Published:
2023-05-10
Contact:
Bin WANG
About author:
WANG Bin, born in 1971, M. S., associate professor. His research interests include evolutionary computing, neural network.Supported by:
通讯作者:
王彬
作者简介:
王彬(1971—),男,陕西西安人,副教授,硕士,CCF会员,主要研究方向:进化计算、神经网络 wb@xaut.edu.cn基金资助:
CLC Number:
Bin WANG, Tian XIANG, Yidong LYU, Xiaofan WANG. Adaptive multi-scale feature channel grouping optimization algorithm based on NSGA‑Ⅱ[J]. Journal of Computer Applications, 2023, 43(5): 1401-1408.
王彬, 向甜, 吕艺东, 王晓帆. 基于NSGA‑Ⅱ的自适应多尺度特征通道分组优化算法[J]. 《计算机应用》唯一官方网站, 2023, 43(5): 1401-1408.
Add to citation manager EndNote|Ris|BibTeX
URL: https://www.joca.cn/EN/10.11772/j.issn.1001-9081.2022040581
结构 | 平均精确度/% | 运行时间/s |
---|---|---|
M_blockNet_v1 | 91.492 5 | 8 176 |
MobileNet_v1 | 80.187 8 | 1 883 |
MobileNet_v2 | 83.333 5 | 2 162 |
ShuffleNet_v2 | 89.328 7 | 1 791 |
DenseNet | 91.734 1 | 4 862 |
SSCA_MblockNet | 92.300 5 | 5 132 |
NSGA2-AMFFNetwork | 92.712 7 | 4 818 |
Tab. 1 Comparison of average test accuracy and running time
结构 | 平均精确度/% | 运行时间/s |
---|---|---|
M_blockNet_v1 | 91.492 5 | 8 176 |
MobileNet_v1 | 80.187 8 | 1 883 |
MobileNet_v2 | 83.333 5 | 2 162 |
ShuffleNet_v2 | 89.328 7 | 1 791 |
DenseNet | 91.734 1 | 4 862 |
SSCA_MblockNet | 92.300 5 | 5 132 |
NSGA2-AMFFNetwork | 92.712 7 | 4 818 |
解序号 | NSGA2-AMFFModule1 | NSGA2-AMFFModule2 | ||||
---|---|---|---|---|---|---|
1×1 点卷积 | 3×3 标准卷积 | 3×3 膨胀卷积 | 1×1 点卷积 | 3×3 标准卷积 | 3×3 膨胀卷积 | |
1 | 27 | 58 | 11 | 175 | 34 | 21 |
2 | 97 | 7 | 10 | 192 | 20 | 28 |
3 | 80 | 5 | 11 | 198 | 13 | 29 |
Tab. 2 Channel grouping parameters of NSGA2-AMFFNetwork modules
解序号 | NSGA2-AMFFModule1 | NSGA2-AMFFModule2 | ||||
---|---|---|---|---|---|---|
1×1 点卷积 | 3×3 标准卷积 | 3×3 膨胀卷积 | 1×1 点卷积 | 3×3 标准卷积 | 3×3 膨胀卷积 | |
1 | 27 | 58 | 11 | 175 | 34 | 21 |
2 | 97 | 7 | 10 | 192 | 20 | 28 |
3 | 80 | 5 | 11 | 198 | 13 | 29 |
LCNN | 模块参数总量 | 模块计算总量/107 | 平均 精确度/% | 运行 时间/s |
---|---|---|---|---|
M_blockNet_v1 | 6 656 | 68.640 8 | 91.492 5 | 8 176 |
NSGA2-AMFFNetwork | 48 312 | 42.135 6 | 92.712 7 | 4 818 |
Tab. 3 Comparison results of complexity and accuracy before and after LCNN optimization
LCNN | 模块参数总量 | 模块计算总量/107 | 平均 精确度/% | 运行 时间/s |
---|---|---|---|---|
M_blockNet_v1 | 6 656 | 68.640 8 | 91.492 5 | 8 176 |
NSGA2-AMFFNetwork | 48 312 | 42.135 6 | 92.712 7 | 4 818 |
1 | 武文娟,李勇. Emfacenet:一种轻量级人脸识别的卷积神经网络[J/OL]. 小型微型计算机系统 (2021-12-17) [2022-03-21].. 10.3390/s21175901 |
WU W J, LI Y. Emfacenet: a lightweight convolutional neural network for face recognition[J/OL]. Journal of Chinese Computer Systems (2021-12-17) [2022-03-21].. 10.3390/s21175901 | |
2 | 钱慧芳,易剑平,付云虎. 基于深度学习的人体动作识别综述[J]. 计算机科学与探索, 2021, 15(3): 438-455. 10.3778/j.issn.1673-9418.2009095 |
QIAN H F, YI J P, FU Y H. Review of human action recognition based on deep learning[J]. Journal of Frontiers of Computer Science and Technology, 2021, 15(3): 438-455. 10.3778/j.issn.1673-9418.2009095 | |
3 | 马利,郑诗雨,牛斌. 应用区域关联自适应图卷积的动作识别方法[J]. 计算机科学与探索, 2022, 16(4):898-908. 10.3778/j.issn.1673-9418.2010070 |
MA L, ZHENG S Y, NIU B. Action recognition method on regional association adaptive graph convolution[J]. Journal of Frontiers of Computer Science and Technology, 2022, 16(4):898-908. 10.3778/j.issn.1673-9418.2010070 | |
4 | SINGH S P, KUMAR A, DARBARI H, et al. Machine translation using deep learning: an overview[C]// Proceedings of the 2017 International Conference on Computer, Communications and Electronics. Piscataway: IEEE, 2017: 162-167. 10.1109/comptelix.2017.8003957 |
5 | SCHMIDHUBER J. Deep learning in neural networks: an overview[J]. Neural Networks, 2015, 61: 85-117. 10.1016/j.neunet.2014.09.003 |
6 | 徐子豪,黄伟泉,王胤. 基于深度学习的监控视频中多类别车辆检测[J]. 计算机应用, 2019, 39(3): 700-705. 10.11772/j.issn.1001-9081.2018071587 |
XU Z H, HUANG W Q, WANG Y. Multi-class vehicle detection in surveillance video based on deep learning[J]. Journal of Computer Applications, 2019, 39(3): 700-705. 10.11772/j.issn.1001-9081.2018071587 | |
7 | 周飞燕,金林鹏,董军. 卷积神经网络研究综述[J]. 计算机学报, 2017, 40(6): 1229-1251. 10.11897/SP.J.1016.2017.01229 |
ZHOU F Y, JIN L P, DONG J. Review of convolutional neural network[J]. Chinese Journal of Computers, 2017, 40(6): 1229-1251. 10.11897/SP.J.1016.2017.01229 | |
8 | 朱叶,余宜林,郭迎春. HRDA-Net:面向真实场景的图像多篡改检测与定位算法[J]. 通信学报, 2022, 43(1): 217-226. 10.11959/j.issn.1000-436x.2022016 |
ZHU Y, YU Y L, GUO Y C. HRDA-Net: image multiple manipulation detection and location algorithm in real scene[J]. Journal on Communications, 2022, 43(1): 217-226. 10.11959/j.issn.1000-436x.2022016 | |
9 | GHAYOUMI M. A quick review of deep learning in facial expression[J]. Journal of Communication and Computer, 2017, 14: 34-38. 10.17265/1548-7709/2017.01.004 |
10 | 孟亮,郭小燕,杜佳举,等. 一种轻量级CNN农作物病害图像识别模型[J]. 江苏农业学报, 2021, 37(5): 1143-1150. 10.3969/j.issn.1000-4440.2021.05.008 |
MENG L, GUO X Y, DU J J, et al. A lightweight CNN model for image recognition of crop diseases[J]. Jiangsu Journal of Agricultural Sciences, 2021, 37(5): 1143-1150. 10.3969/j.issn.1000-4440.2021.05.008 | |
11 | 井望,李汪根,沈公仆,等. 轻量级多信息图卷积神经网络动作识别方法[J]. 计算机应用研究, 2022, 39(4): 1247-1252. |
JING W, LI W G, SHEN G P, et al. Lightweight multi-information graph convolution neural network action recognition method[J]. Application Research of Computers, 2022, 39(4): 1247-1252. | |
12 | 毕鹏程,罗健欣,陈卫卫. 轻量化卷积神经网络技术研究[J]. 计算机工程与应用, 2019, 55(16): 25-35. |
BI P C, LUO J X, CHEN W W. Research on lightweight convolutional neural network technology[J]. Computer Engineering and Applications, 2019, 55(16): 25-35. | |
13 | 廖干洲. 轻量化卷积神经网络技术综述[J]. 新一代信息技术, 2020, 3(10): 36-40. 10.3969/j.issn.2096-6091.2020.10.007 |
LIAO G Z. Overview of lightweight convolutional neural network technology[J]. New Generation Information Technology, 2020, 3(10): 36-40. 10.3969/j.issn.2096-6091.2020.10.007 | |
14 | SUN Y N, XUE B, ZHANG M J, et al. An experimental study on hyper-parameter optimization for stacked auto-encoders[C]// Proceedings of the 2018 IEEE Congress on Evolutionary Computation. Piscataway: IEEE, 2018: 1-8. 10.1109/cec.2018.8477921 |
15 | 王伟,孙成胜,伍少梅,等. 一种轻量级文本蕴含模型[J]. 四川大学学报(自然科学版), 2021, 58(5): No.052001. 10.19907/j.0490-6756.2021.052001 |
WANG W, SUN C S, WU S M, et al. A lightweight text entailment model[J]. Journal of Sichuan University (Natural Science Edition), 2021, 58(5): No.052001. 10.19907/j.0490-6756.2021.052001 | |
16 | 许虞俊,李晨. 基于YOLO优化的轻量级目标检测网络[J]. 计算机科学, 2021, 48(11A): 265-269. 10.11896/jsjkx.201000152 |
XU Y J, LI C. Light-weight object detection network optimized based on YOLO family[J]. Computer Science, 2021, 48(11A): 265-269. 10.11896/jsjkx.201000152 | |
17 | 徐晓,蒋志翔,张杨. 基于通道剪枝和量化的卷积神经网络压缩方法[J]. 计算机工程与设计, 2021, 42(10): 2860-2866. |
XU X, JIANG Z X, ZHANG Y. Convolution neural network compression method based on channel pruning and quantization[J]. Computer Engineering and Design, 2021, 42(10): 2860-2866. | |
18 | DEB K, PRATAP A, AGARWAL S, et al. A fast and elitist multiobjective genetic algorithm: NSGA-Ⅱ[J]. IEEE Transactions on Evolutionary Computation, 2002, 6(2): 182-197. 10.1109/4235.996017 |
19 | ZITZLER E, LAUMANNS M, THIELE L. SPEA2: improving the strength Pareto evolutionary algorithm[R/OL]. (2001-05) [2022-03-22].. |
20 | LALWANI S, SINGHAL S, KUMAR R, et al. A comprehensive survey: applications of Multi-Objective Particle Swarm Optimization (MOPSO) algorithm[J]. Transactions on Combinatorics, 2013, 2(1): 39-101. |
21 | CORNE D W, JERRAM N R, KNOWLES J D, et al. PESA-Ⅱ: region-based selection in evolutionary multiobjective optimization[C]// Proceedings of the 3rd Annual Conference on Genetic and Evolutionary Computation Conference. San Francisco: Morgan Kaufmann Publishers Inc., 2001:283-290. |
22 | ZHANG Q F, LI H. MOEA/D: a multiobjective evolutionary algorithm based on decomposition[J]. IEEE Transactions on Evolutionary Computation, 2007, 11(6): 712-731. 10.1109/tevc.2007.892759 |
23 | ZITZLER E, KÜNZLI S. Indicator-based selection in multi objective search[C]// Proceedings of the 2004 International Conference on Parallel Problem Solving from Nature, LNCS 3242. Berlin: Springer, 2004: 832-842. |
24 | WANG B, SUN Y N, XUE B, et al. Evolving deep convolutional neural networks by variable-length particle swarm optimization for image classification[C]// Proceedings of the 2018 IEEE Congress on Evolutionary Computation. Piscataway: IEEE, 2018: 1-8. 10.1109/cec.2018.8477735 |
25 | SUN Y N, XUE B, ZHANG M J, et al. An experimental study on hyper-parameter optimization for stacked auto-encoders[C]// Proceedings of the 2018 IEEE Congress on Evolutionary Computation. Piscataway: IEEE, 2018: 1-8. 10.1109/cec.2018.8477921 |
26 | LU Z C, WHALEN I, BODDETI V, et al. NSGA-Net: neural architecture search using multi-objective genetic algorithm[C]// Proceedings of the 2019 Genetic and Evolutionary Computation Conference. New York: ACM, 2019: 419-427. 10.1145/3321707.3321729 |
27 | 西安理工大学. 基于非均匀分组的多尺度轻量型深度卷积神经网络模型:202010505261.4[P]. 2020-11-10. |
Xi’an University of Technology. Multi-scale lightweight deep convolutional neural network model based on non-uniform grouping: 202010505261.4[P]. 2020-11-10. | |
28 | 西安理工大学. 一种自动分组的多尺度轻量型深度卷积神经网络优化方法: 202110251256.X[P]. 2021-06-22. |
Xi’an University of Technology. An automatic grouping multi-scale lightweight deep convolutional neural network optimization method: 202110251256.X[P]. 2021-06-22. | |
29 | YANG J C, SHI R, WEI D L, et al. MedMNIST v2: a large-scale lightweight benchmark for 2D and 3D biomedical image classification[J]. Scientific Data, 2023, 10: No.41. 10.1038/s41597-022-01721-8 |
30 | HOWARD A G, ZHU M L, CHEN B, et al. MobileNets: efficient convolutional neural networks for mobile vision applications[EB/OL]. (2017-04-17) [2022-03-22].. 10.48550/arXiv.1704.04861 |
31 | SANDLER M, HOWARD A, ZHU M L, et al. MobileNetV2: inverted residuals and linear bottlenecks[C]// Proceedings of the 2018 IEEE/CVF Conference on Computer Vision and Pattern Recognition. Piscataway: IEEE, 2018: 4510-4520. 10.1109/cvpr.2018.00474 |
32 | MA N N, ZHANG X Y, ZHENG H T, et al. ShuffleNet V2: practical guidelines for efficient CNN architecture design[C]// Proceedings of the 2018 European Conference on Computer Vision, LNCS 11218. Cham: Springer, 2018: 122-138. |
33 | HUANG G, LIU Z, L van der MAATEN, et al. Densely connected convolutional networks[C]// Proceedings of the 2017 International Conference on Computer Vision and Pattern Recognition. Piscataway: IEEE, 2017: 2261-2269. 10.1109/cvpr.2017.243 |
