Journal of Computer Applications ›› 2023, Vol. 43 ›› Issue (8): 2382-2389.DOI: 10.11772/j.issn.1001-9081.2022071103
Special Issue: 人工智能
• Artificial intelligence • Previous Articles Next Articles
Zexi JIN1, Lei LI1,2, Ji LIU1,2
Received:
2022-07-29
Revised:
2022-11-21
Accepted:
2022-11-30
Online:
2023-01-15
Published:
2023-08-10
Contact:
Lei LI
About author:
JIN Zexi, born in 1998, M. S. candidate. His research interests include machine learning, big data analysis.Supported by:
金泽熙1, 李磊1,2, 刘继1,2
通讯作者:
李磊
作者简介:
金泽熙(1998—),男,江苏盐城人,硕士研究生,主要研究方向:机器学习、大数据分析基金资助:
CLC Number:
Zexi JIN, Lei LI, Ji LIU. Transfer learning model based on improved domain separation network[J]. Journal of Computer Applications, 2023, 43(8): 2382-2389.
金泽熙, 李磊, 刘继. 基于改进领域分离网络的迁移学习模型[J]. 《计算机应用》唯一官方网站, 2023, 43(8): 2382-2389.
Add to citation manager EndNote|Ris|BibTeX
URL: https://www.joca.cn/EN/10.11772/j.issn.1001-9081.2022071103
参数类型 | 可调参数 | 值 |
---|---|---|
胶囊 网络 参数 | 初始胶囊维度 | 16 |
主胶囊维度 | 32 | |
动态路由次数Routing | 3 | |
胶囊网络优化函数 | Adam | |
模型 训练 参数 | 学习率lr | 0.001 |
迭代次数epoch | 20 | |
批处理大小batch_size | 32 |
Tab.1 Parameter setting of AMCN-DSN model
参数类型 | 可调参数 | 值 |
---|---|---|
胶囊 网络 参数 | 初始胶囊维度 | 16 |
主胶囊维度 | 32 | |
动态路由次数Routing | 3 | |
胶囊网络优化函数 | Adam | |
模型 训练 参数 | 学习率lr | 0.001 |
迭代次数epoch | 20 | |
批处理大小batch_size | 32 |
模型 | 源域数据集 | 目标域数据集 | ||
---|---|---|---|---|
F1 | P | R | F1 | |
DCGAN[ | 0.855 3 | 0.773 9 | 0.784 1 | 0.779 0 |
DANN[ | 0.895 4 | 0.810 4 | 0.812 6 | 0.811 5 |
DANN+CapsNet[ | 0.915 5 | 0.824 2 | 0.831 5 | 0.827 8 |
ADDA[ | 0.902 1 | 0.819 2 | 0.816 5 | 0.817 8 |
Res-CapsNet[ | 0.917 4 | 0.832 2 | 0.830 7 | 0.831 4 |
DAAN[ | 0.910 2 | 0.829 5 | 0.832 2 | 0.830 8 |
ASDA[ | 0.889 6 | 0.807 9 | 0.797 0 | 0.802 4 |
AMCN-DSN | 0.9239 | 0.8577 | 0.8429 | 0.8502 |
Tab.2 Performance comparison of transfer learning models in sentiment analysis
模型 | 源域数据集 | 目标域数据集 | ||
---|---|---|---|---|
F1 | P | R | F1 | |
DCGAN[ | 0.855 3 | 0.773 9 | 0.784 1 | 0.779 0 |
DANN[ | 0.895 4 | 0.810 4 | 0.812 6 | 0.811 5 |
DANN+CapsNet[ | 0.915 5 | 0.824 2 | 0.831 5 | 0.827 8 |
ADDA[ | 0.902 1 | 0.819 2 | 0.816 5 | 0.817 8 |
Res-CapsNet[ | 0.917 4 | 0.832 2 | 0.830 7 | 0.831 4 |
DAAN[ | 0.910 2 | 0.829 5 | 0.832 2 | 0.830 8 |
ASDA[ | 0.889 6 | 0.807 9 | 0.797 0 | 0.802 4 |
AMCN-DSN | 0.9239 | 0.8577 | 0.8429 | 0.8502 |
模型 | 源域数据集 | 目标域数据集 | ||
---|---|---|---|---|
F1 | P | R | F1 | |
DCGAN[ | 0.746 3 | 0.658 7 | 0.651 4 | 0.655 0 |
DANN[ | 0.791 0 | 0.702 7 | 0.706 9 | 0.704 8 |
DANN+CapsNet[ | 0.823 1 | 0.742 6 | 0.741 1 | 0.741 8 |
ADDA[ | 0.802 5 | 0.712 2 | 0.701 6 | 0.706 9 |
Res-CapsNet[ | 0.815 8 | 0.740 9 | 0.740 3 | 0.740 6 |
DAAN[ | 0.821 4 | 0.735 9 | 0.733 2 | 0.734 5 |
ADSA[ | 0.771 9 | 0.673 3 | 0.691 4 | 0.682 2 |
AMCN-DSN | 0.8439 | 0.7758 | 0.7733 | 0.7745 |
Tab.3 Performance comparison of transfer learning models in intent recognition
模型 | 源域数据集 | 目标域数据集 | ||
---|---|---|---|---|
F1 | P | R | F1 | |
DCGAN[ | 0.746 3 | 0.658 7 | 0.651 4 | 0.655 0 |
DANN[ | 0.791 0 | 0.702 7 | 0.706 9 | 0.704 8 |
DANN+CapsNet[ | 0.823 1 | 0.742 6 | 0.741 1 | 0.741 8 |
ADDA[ | 0.802 5 | 0.712 2 | 0.701 6 | 0.706 9 |
Res-CapsNet[ | 0.815 8 | 0.740 9 | 0.740 3 | 0.740 6 |
DAAN[ | 0.821 4 | 0.735 9 | 0.733 2 | 0.734 5 |
ADSA[ | 0.771 9 | 0.673 3 | 0.691 4 | 0.682 2 |
AMCN-DSN | 0.8439 | 0.7758 | 0.7733 | 0.7745 |
模型 | 情感分析任务 | 意图识别任务 | ||||||
---|---|---|---|---|---|---|---|---|
源域 | 目标域 | 源域 | 目标域 | |||||
F1 | P | R | F1 | F1 | P | R | F1 | |
DSN[ | 0.892 4 | 0.809 2 | 0.795 5 | 0.802 2 | 0.774 2 | 0.686 1 | 0.691 8 | 0.688 9 |
AMCN-DSN(-MSHA, | 0.910 2 | 0.816 6 | 0.819 5 | 0.822 7 | 0.814 7 | 0.732 3 | 0.739 8 | 0.736 0 |
AMCN-DSN( | 0.903 7 | 0.835 0 | 0.841 6 | 0.838 3 | 0.826 8 | 0.747 5 | 0.746 6 | 0.747 0 |
AMCN-DSN(-MSHA) | 0.914 5 | 0.844 2 | 0.836 9 | 0.840 5 | 0.833 5 | 0.756 3 | 0.753 5 | 0.754 9 |
AMCN-DSN | 0.9239 | 0.8577 | 0.8429 | 0.8502 | 0.8439 | 0.7758 | 0.7733 | 0.7745 |
Tab.4 Ablation experimental results on sentiment analysis and intent recognition tasks
模型 | 情感分析任务 | 意图识别任务 | ||||||
---|---|---|---|---|---|---|---|---|
源域 | 目标域 | 源域 | 目标域 | |||||
F1 | P | R | F1 | F1 | P | R | F1 | |
DSN[ | 0.892 4 | 0.809 2 | 0.795 5 | 0.802 2 | 0.774 2 | 0.686 1 | 0.691 8 | 0.688 9 |
AMCN-DSN(-MSHA, | 0.910 2 | 0.816 6 | 0.819 5 | 0.822 7 | 0.814 7 | 0.732 3 | 0.739 8 | 0.736 0 |
AMCN-DSN( | 0.903 7 | 0.835 0 | 0.841 6 | 0.838 3 | 0.826 8 | 0.747 5 | 0.746 6 | 0.747 0 |
AMCN-DSN(-MSHA) | 0.914 5 | 0.844 2 | 0.836 9 | 0.840 5 | 0.833 5 | 0.756 3 | 0.753 5 | 0.754 9 |
AMCN-DSN | 0.9239 | 0.8577 | 0.8429 | 0.8502 | 0.8439 | 0.7758 | 0.7733 | 0.7745 |
1 | SCHMIDHUBER J. Deep learning in neural networks: an overview[J]. Neural Networks, 2015, 61: 85-117. 10.1016/j.neunet.2014.09.003 |
2 | ZHUANG F Z, QI Z Y, DUAN K Y, et al. A comprehensive survey on transfer learning[J]. Proceedings of the IEEE, 2021, 109(1): 43-76. 10.1109/jproc.2020.3004555 |
3 | 吴冬茵,桂林,陈钊,等. 基于深度表示学习和高斯过程迁移学习的情感分析方法[J]. 中文信息学报, 2017, 31(1): 169-176. |
WU D Y, GUI L, CHEN Z, et al. Sentiment analysis based on deep representation learning and Gaussian processes transfer learning[J]. Journal of Chinese Information Processing, 2017, 31(1):169-176. | |
4 | 赵鹏飞,李艳玲,林民. 结合胶囊网络的领域适应意图识别[J]. 计算机工程与应用, 2021, 57(21): 188-194. |
ZHAO P F, LI Y L, LIN M. Intent detection of domain adaptation combined with capsule network[J]. Computer Engineering and Applications, 2021, 57(21): 188-194. | |
5 | 范涛,王昊,陈玥彤. 基于深度迁移学习的地方志多模态命名实体识别研究[J]. 情报学报, 2022, 41(4): 412-423. 10.3772/j.issn.1000-0135.2022.04.008 |
FAN T, WANG H, CHEN Y T. Research on multimodal named entity recognition of local history based on deep transfer learning[J]. Journal of the China Society for Scientific and Technical Information, 2022, 41(4): 412-423. 10.3772/j.issn.1000-0135.2022.04.008 | |
6 | 赵鹏飞,李艳玲,林民. 面向迁移学习的意图识别研究进展[J]. 计算机科学与探索, 2020, 14(8): 1261-1274. |
ZHAO P F, LI Y L, LIN M. Research progress on intent detection oriented to transfer learning[J]. Journal of Frontiers of Computer Science and Technology, 2020, 14(8): 1261-1274. | |
7 | PAN S J, YANG Q. A survey on transfer learning[J]. IEEE Transactions on Knowledge and Data Engineering, 2010, 22(10): 1345-1359. 10.1109/tkde.2009.191 |
8 | DAI W Y, YANG Q, XUE G R, et al. Boosting for transfer learning[C]// Proceedings of the 24th International Conference on Machine Learning. New York: ACM, 2007:193-200. 10.1145/1273496.1273521 |
9 | BO C, LAM W, TSANG I, et al. Extracting discriminative concepts for domain adaptation in text mining[C]// Proceedings of the 15th ACM SIGKDD International Conference on Knowledge Discovery and Data Mining. New York: ACM, 2009:179-188. 10.1145/1557019.1557045 |
10 | CHANG H, HAN J, ZHONG C, et al. Unsupervised transfer learning via multi-scale convolutional sparse coding for biomedical applications[J]. IEEE Transactions on Pattern Analysis and Machine Intelligence, 2018, 40(5): 1182-1194. 10.1109/tpami.2017.2656884 |
11 | GOODFELLOW I, POUGET-ABADIE J, MIRZA M, et al. Generative adversarial nets[C]// Proceedings of the 27th International Conference on Neural Information Processing Systems - Volume 2. Cambridge: MIT Press, 2014:2672-2680. |
12 | GANIN Y, USTINOVA E, AJAKAN H, et al. Domain-adversarial training of neural networks[J]. Journal of Machine Learning Research, 2016, 17: 1-35. 10.1007/978-3-319-58347-1_10 |
13 | TZENG E, HOFFMAN J, DARRELL T, et al. Simultaneous deep transfer across domains and tasks[C]// Proceedings of the 2015 IEEE International Conference on Computer Vision. Piscataway: IEEE, 2015: 4068-4076. 10.1109/iccv.2015.463 |
14 | TZENG E, HOFFMAN J, SAENKO K, et al. Adversarial discriminative domain adaptation[C]// Proceedings of the 2017 IEEE Conference on Computer Vision and Pattern Recognition. Piscataway: IEEE, 2017: 2962-2971. 10.1109/cvpr.2017.316 |
15 | YU C H, WANG J D, CHEN Y Q, et al. Transfer learning with dynamic adversarial adaptation network[C]// Proceedings of the 2019 IEEE International Conference on Data Mining. Piscataway: IEEE, 2019: 778-786. 10.1109/icdm.2019.00088 |
16 | BOUSMALIS K, TRIGEORGIS G, SILBERMAN N, et al. Domain separation networks[C]// Proceedings of the 30th International Conference on Neural Information Processing Systems. Red Hook, NY: Curran Associates Inc., 2016:343-351. |
17 | TSAI J C, CHIEN J T. Adversarial domain separation and adaptation[C]// Proceedings of the IEEE 27th International Workshop on Machine Learning for Signal Processing. Piscataway: IEEE, 2017: 1-6. 10.1109/mlsp.2017.8168121 |
18 | BEN-DAVID S, BLITZER J, CRAMMER K, et al. Analysis of representations for domain adaptation[C]// Proceedings of the 19th International Conference on Neural Information Processing Systems. Cambridge: MIT Press, 2006:137-144. 10.7551/mitpress/7503.003.0022 |
19 | BEN-DAVID S, BLITZER J, CRAMMER K, et al. A theory of learning from different domains[J]. Machine Learning, 2010, 79(1/2): 151-175. 10.1007/s10994-009-5152-4 |
20 | 王家乾,龚子寒,薛云,等. 基于混合多头注意力和胶囊网络的特定目标情感分析[J]. 中文信息学报, 2020, 34(5): 100-110. 10.3969/j.issn.1003-0077.2020.05.014 |
WANG J Q, GONG Z H, XUE Y, et al. Aspect-based sentiment analysis based on hybrid multi-head attention and capsule networks[J]. Journal of Chinese Information Processing, 2020, 34(5): 100-110. 10.3969/j.issn.1003-0077.2020.05.014 | |
21 | China Computer Federation. NLPCC 2014 Evaluation tasks test data download[DB/OL]. [2022-11-20].. |
22 | Corporation iFLYTEK. SMP2018-ECDT task 1 dataset[DS/OL]. [2022-11-20].. |
23 | FANG W, ZHANG F H, SHENG V S, et al. A method for improving CNN-based image recognition using DCGAN[J]. Computers, Materials and Continua, 2018, 57(1): 167-178. 10.32604/cmc.2018.02356 |
24 | 戴宏,盛立杰,苗启广. 基于胶囊网络的对抗判别域适应算法[J]. 计算机研究与发展, 2021, 58(9): 1997-2012. 10.7544/issn1000-1239.2021.20200569 |
DAI H, SHENG L J, MIAO Q G. Adversarial discriminative domain adaptation algorithm with CapsNet[J]. Journal of Computer Research and Development, 2021, 58(9): 1997-2012. 10.7544/issn1000-1239.2021.20200569 |
