Journal of Computer Applications ›› 2023, Vol. 43 ›› Issue (11): 3464-3471.DOI: 10.11772/j.issn.1001-9081.2022111774
Special Issue: 数据科学与技术
• Data science and technology • Previous Articles Next Articles
Received:
2022-11-28
Revised:
2023-03-22
Accepted:
2023-03-23
Online:
2023-04-07
Published:
2023-11-10
Contact:
Qiwen SHI
About author:
WANG Yonggui, born in 1967, M. S., professor. His research interests include big data, parallel computing, database, data mining.Supported by:
通讯作者:
时启文
作者简介:
王永贵(1967—),男,内蒙古赤峰人,教授,硕士,CCF会员,主要研究方向:大数据、并行计算、数据库、数据挖掘CLC Number:
Yonggui WANG, Qiwen SHI. Social recommendation by enhanced GNN with heterogeneous relationship[J]. Journal of Computer Applications, 2023, 43(11): 3464-3471.
王永贵, 时启文. 结合异构关系增强图神经网络的社交推荐[J]. 《计算机应用》唯一官方网站, 2023, 43(11): 3464-3471.
Add to citation manager EndNote|Ris|BibTeX
URL: https://www.joca.cn/EN/10.11772/j.issn.1001-9081.2022111774
数据集 | 用户数 | 项目数 | 用户-项目评分数 | 用户-用户社交数 |
---|---|---|---|---|
Ciao | 7 374 | 105 059 | 282 163 | 111 781 |
Epinions | 26 337 | 139 738 | 664 832 | 487 182 |
Tab. 1 Statistics of datasets
数据集 | 用户数 | 项目数 | 用户-项目评分数 | 用户-用户社交数 |
---|---|---|---|---|
Ciao | 7 374 | 105 059 | 282 163 | 111 781 |
Epinions | 26 337 | 139 738 | 664 832 | 487 182 |
序号 | Ciao | Epinions | ||
---|---|---|---|---|
MAE | RMSE | MAE | RMSE | |
均值 | 0.719 4 | 0.949 5 | 0.777 2 | 1.015 0 |
1 | 0.719 7 | 0.949 8 | 0.771 2 | 1.014 8 |
2 | 0.720 1 | 0.949 5 | 0.782 6 | 1.015 4 |
3 | 0.719 3 | 0.949 3 | 0.771 7 | 1.014 4 |
4 | 0.718 7 | 0.949 1 | 0.775 7 | 1.015 2 |
5 | 0.719 4 | 0.949 7 | 0.785 1 | 1.015 6 |
Tab. 2 Mean results of HR-GNN model running 5 times
序号 | Ciao | Epinions | ||
---|---|---|---|---|
MAE | RMSE | MAE | RMSE | |
均值 | 0.719 4 | 0.949 5 | 0.777 2 | 1.015 0 |
1 | 0.719 7 | 0.949 8 | 0.771 2 | 1.014 8 |
2 | 0.720 1 | 0.949 5 | 0.782 6 | 1.015 4 |
3 | 0.719 3 | 0.949 3 | 0.771 7 | 1.014 4 |
4 | 0.718 7 | 0.949 1 | 0.775 7 | 1.015 2 |
5 | 0.719 4 | 0.949 7 | 0.785 1 | 1.015 6 |
算法 | Ciao | Epinions | ||
---|---|---|---|---|
MAE | RMSE | MAE | RMSE | |
PMF | 0.902 1 | 1.123 8 | 0.995 2 | 1.212 8 |
SocialMF | 0.832 1 | 1.065 7 | 0.883 7 | 1.132 8 |
SoReg | 0.898 7 | 1.094 7 | 0.941 2 | 1.193 6 |
SAMN | 0.811 6 | 1.092 4 | 0.899 5 | 1.189 9 |
EATNN | 0.797 3 | 1.074 2 | 0.866 3 | 1.138 5 |
GraphRec | 0.759 1 | 1.009 3 | 0.844 1 | 1.087 8 |
Danser | 0.740 3 | 0.990 4 | 0.813 9 | 1.075 6 |
ASR | ||||
ConsisRec | 0.739 4 | 0.972 2 | 0.804 6 | 1.049 5 |
HR-GNN | 0.719 4 | 0.949 5 | 0.777 2 | 1.015 0 |
Tab. 3 Experimental results of different models on two datasets
算法 | Ciao | Epinions | ||
---|---|---|---|---|
MAE | RMSE | MAE | RMSE | |
PMF | 0.902 1 | 1.123 8 | 0.995 2 | 1.212 8 |
SocialMF | 0.832 1 | 1.065 7 | 0.883 7 | 1.132 8 |
SoReg | 0.898 7 | 1.094 7 | 0.941 2 | 1.193 6 |
SAMN | 0.811 6 | 1.092 4 | 0.899 5 | 1.189 9 |
EATNN | 0.797 3 | 1.074 2 | 0.866 3 | 1.138 5 |
GraphRec | 0.759 1 | 1.009 3 | 0.844 1 | 1.087 8 |
Danser | 0.740 3 | 0.990 4 | 0.813 9 | 1.075 6 |
ASR | ||||
ConsisRec | 0.739 4 | 0.972 2 | 0.804 6 | 1.049 5 |
HR-GNN | 0.719 4 | 0.949 5 | 0.777 2 | 1.015 0 |
模型 | 数据集 | 平均训练时间/s |
---|---|---|
GraphRec | Ciao | 221.84 |
Epinions | 587.04 | |
Danser | Ciao | 315.46 |
Epinions | 663.12 | |
ASR | Ciao | 269.31 |
Epinions | 729.63 | |
ConsisRec | Ciao | 1 500.55 |
Epinions | 2 818.32 | |
HR-GNN | Ciao | 256.81 |
Epinions | 621.24 |
Tab. 4 Average training time of different models on two datasets
模型 | 数据集 | 平均训练时间/s |
---|---|---|
GraphRec | Ciao | 221.84 |
Epinions | 587.04 | |
Danser | Ciao | 315.46 |
Epinions | 663.12 | |
ASR | Ciao | 269.31 |
Epinions | 729.63 | |
ConsisRec | Ciao | 1 500.55 |
Epinions | 2 818.32 | |
HR-GNN | Ciao | 256.81 |
Epinions | 621.24 |
模型 | 参数量/106 | 模型大小/MB | 占用内存/GB |
---|---|---|---|
GraphRec | 3.88 | 14.81 | 1.49 |
Danser | 3.85 | 14.68 | 1.42 |
ASR | 3.91 | 14.91 | 1.56 |
ConsisRec | 3.82 | 14.56 | 1.38 |
HR-GNN | 3.86 | 14.72 | 1.44 |
Tab. 5 Parametric quantitative analysis of different models
模型 | 参数量/106 | 模型大小/MB | 占用内存/GB |
---|---|---|---|
GraphRec | 3.88 | 14.81 | 1.49 |
Danser | 3.85 | 14.68 | 1.42 |
ASR | 3.91 | 14.91 | 1.56 |
ConsisRec | 3.82 | 14.56 | 1.38 |
HR-GNN | 3.86 | 14.72 | 1.44 |
1 | YANG B, LEI Y, LIU J, et al. Social collaborative filtering by trust[J]. IEEE Transactions on Pattern Analysis and Machine Intelligence, 2017, 39(8): 1633-1647. 10.1109/tpami.2016.2605085 |
2 | JAMALI M, ESTER M. A matrix factorization technique with trust propagation for recommendation in social networks[C]// Proceedings of the 4th ACM Conference on Recommender Systems. New York: ACM, 2010: 135-142. 10.1145/1864708.1864736 |
3 | ABADAL S, JAIN A, GUIRADO R, et al. Computing graph neural networks: a survey from algorithms to accelerators[J]. ACM Computing Surveys, 2022, 54(9): No.191. 10.1145/3477141 |
4 | FAN W, LI Q, CHENG M. Deep modeling of social relations for recommendation[C]// Proceedings of the 32nd AAAI Conference on Artificial Intelligence. Palo Alto, CA: AAAI Press, 2018: 8075-8076. 10.1609/aaai.v32i1.12132 |
5 | LIU Z, DOU Y, YU P S, et al. Alleviating the inconsistency problem of applying graph neural network to fraud detection[C]// Proceedings of the 43rd International ACM SIGIR Conference on Research and Development in Information Retrieval. New York: ACM, 2020: 1569-1572. 10.1145/3397271.3401253 |
6 | LIU Z, LI X, FAN Z, et al. Basket recommendation with multi-intent translation graph neural network[C]// Proceedings of the 2020 IEEE International Conference on Big Data. Piscataway: IEEE, 2020: 728-737. 10.1109/bigdata50022.2020.9377917 |
7 | KRASNOVA H, WIDJAJA T, BUXMANN P, et al. Research note — why following friends can hurt you: an exploratory investigation of the effects of envy on social networking sites among college-age users[J]. Information Systems Research, 2015, 26(3): 585-605. 10.1287/isre.2015.0588 |
8 | SONG L, BI Y, YAO M, et al. DREAM: a dynamic relation-aware model for social recommendation[C]// Proceedings of the 29th ACM International Conference on Information and Knowledge Management. New York: ACM, 2020: 2225-2228. 10.1145/3340531.3412115 |
9 | FU M, QU H, YI Z, et al. A novel deep learning-based collaborative filtering model for recommendation system[J]. IEEE Transactions on Cybernetics, 2019, 49(3): 1084-1096.. 10.1109/tcyb.2018.2795041 |
10 | NI J, HUANG Z, CHENG J, et al. An effective recommendation model based on deep representation learning[J]. Information Sciences, 2021, 542: 324-342. 10.1016/j.ins.2020.07.038 |
11 | BAHDANAU D, CHO K, BENGIO Y. Neural machine translation by jointly learning to align and translate[EB/OL]. (2016-05-19) [2022-09-13].. 10.1017/9781108608480.003 |
12 | WU L, SUN P, FU Y, et al. A neural influence diffusion model for social recommendation[C]// Proceedings of the 42nd International ACM SIGIR Conference on Research and Development in Information Retrieval. New York: ACM, 2019: 235-244. 10.1145/3331184.3331214 |
13 | CHEN C, ZHANG M, LIU Y, et al. Social attentional memory network: modeling aspect-and friend-level differences in recommendation[C]// Proceedings of the 12th ACM International Conference on Web Search and Data Mining. New York: ACM, 2019: 177-185. 10.1145/3289600.3290982 |
14 | CHEN C, ZHANG M, WANG C, et al. An efficient adaptive transfer neural network for social-aware recommendation[C]// Proceedings of the 42nd International ACM SIGIR Conference on Research and Development in Information Retrieval. New York: ACM, 2019: 225-234. 10.1145/3331184.3331192 |
15 | GAO C, WANG X, HE X, et al. Graph neural networks for recommender system[C]// Proceedings of the 15th ACM International Conference on Web Search and Data Mining. New York: ACM, 2022: 1623-1625. 10.1145/3488560.3501396 |
16 | WU S, SUN F, ZHANG W, et al. Graph neural networks in recommender systems: a survey[J]. ACM Computing Surveys, 2023, 55(5): No.97. 10.1145/3535101 |
17 | 黄立威,江碧涛,吕守业,等. 基于深度学习的推荐系统研究综述[J]. 计算机学报, 2018, 41(7):1619-1647. 10.11897/SP.J.1016.2018.01619 |
HUANG L W, JIANG B T, LYU S Y, et al. Survey on deep learning based recommender systems[J]. Chinese Journal of Computers, 2018, 41(7): 1619-1647. 10.11897/SP.J.1016.2018.01619 | |
18 | FAN W, MA Y, LI Q, et al. Graph neural networks for social recommendation[C]// Proceedings of the 2019 World Wide Web Conference. Republic and Canton of Geneva: International World Wide Web Conferences Steering Committee, 2019: 417-426. 10.1145/3308558.3313488 |
19 | WU L, LI J, SUN P, et al. DiffNet++: a neural influence and interest diffusion network for social recommendation[J]. IEEE Transactions on Knowledge and Data Engineering, 2022, 34(10): 4753-4766. 10.1109/tkde.2020.3048414 |
20 | WU Q, ZHANG H, GAO X, et al. Dual graph attention networks for deep latent representation of multifaceted social effects in recommender systems[C]// Proceedings of the 2019 World Wide Web Conference. Republic and Canton of Geneva: International World Wide Web Conferences Steering Committee, 2019: 2091-2102. 10.1145/3308558.3313442 |
21 | LUO D, BIAN Y, ZHANG X, et al. Attentive social recommendation: Towards user and item diversities[EB/OL]. [2022-09-13].. 10.48550/arXiv.2011.04797 |
22 | XU H, HUANG C, XU Y, et al. Global context enhanced social recommendation with hierarchical graph neural networks[C]// Proceedings of the 2020 IEEE International Conference on Data Mining. Piscataway: IEEE, 2020: 701-710. 10.1109/icdm50108.2020.00079 |
23 | YANG L, LIU Z, DOU Y, et al. ConsisRec: enhancing GNN for social recommendation via consistent neighbor aggregation[C]// Proceedings of the 44th International ACM SIGIR Conference on Research and Development in Information Retrieval. New York: ACM, 2021: 2141-2145. 10.1145/3404835.3463028 |
24 | CONG W, FORSATI R, KANDEMIR M, et al. Minimal variance sampling with provable guarantees for fast training of graph neural networks[C]// Proceedings of the 26th ACM SIGKDD International Conference on Knowledge Discovery and Data Mining. New York: ACM, 2020: 1393-1403. 10.1145/3394486.3403192 |
25 | ZENG H, ZHOU H, SRIVASTAVA A, et al. GraphSAINT: graph sampling based inductive learning method[EB/OL]. (2020-02-16) [2022-09-13].. |
26 | CHIANG W L, LIU X, SI S, et al. Cluster-GCN: an efficient algorithm for training deep and large graph convolutional networks[C]// Proceedings of the 25th ACM SIGKDD International Conference on Knowledge Discovery and Data Mining. New York: ACM, 257-266. 10.1145/3292500.3330925 |
27 | SALAKHUTDINOV R, MNIH A. Probabilistic matrix factorization[C]// Proceedings of the 20th International Conference on Neural Information Processing Systems. Red Hook, NY: Curran Associates Inc., 2007: 1257-1264. 10.1145/1390156.1390267 |
28 | MA H, ZHOU D, LIU C, et al. Recommender systems with social regularization[C]// Proceedings of the 4th ACM International Conference on Web Search and Data Mining. New York: ACM, 2011: 287-296. 10.1145/1935826.1935877 |
